Step 6: Send A Fax; Trio Fax; Microsoft Fax - Multitech MultiModemDSVD User Manual

MultiModemDSVD User Guide

Step 6: Send a Fax

To test your modem's fax capabilities, send the completed registration file that you
downloaded in "Step 6: Call the Multi-Tech BBS" to Multi-Tech or to a fax machine
in your office.

Trio Fax

1. Depending on which version of the registration file you downloaded, use either
2. Fill out the registration form and save the file, but do not exit.
3. Select Print from the File menu.
4. In the Name box of the Print dialog box, select Trio DataFax, and then click OK.
5. If you are sending the registration form to your own fax machine or to another
6. Click Next Dialog.
7. Select a cover sheet, and then click Next Dialog.
8. Type a cover sheet message, and then click Next Dialog. A preview window
9. If the fax looks correct, click Send. A dialog box appears that shows the progress
10. When transmission is complete, exit Word or Notepad.

Microsoft Fax

Microsoft Fax is installed in Windows 95 as part of the Microsoft Exchange option.
To install it under Windows 98, you must locate the \tools\oldwin95\message\us
folder on the Windows 98 compact disc. Then, double-click on Wms.exe to install
Windows Messaging. Once you've installed Windows Messaging, double-click on
Awfax.exe to add Microsoft Fax to Windows Messaging.
You can use Microsoft Fax either as a stand-alone fax program or to fax from within
another application. In the following procedure you will test your fax modem by
running Microsoft Fax as a stand-alone fax program.
1. Depending on which version of the registration file you downloaded, use either
2. Fill out the registration form.
3. Save the file and exit Word or NotePad.
4. Select Start | Programs | Accessories | Fax | Compose new fax.
5. The Compose New Fax wizard appears. Click Next.
14
Microsoft Word or NotePad to open the registration file.
After a short pause, the Trio Send Fax dialog box opens.
fax modem in your office, under Temporary recipient, type the destination
name and phone number in the Name and Number boxes.
If you are sending the registration form to our offices, type Multi-Tech Systems
in the Company box, and 612 785-9874 in the Number box.
opens.
of the fax transmission.
Microsoft Word or NotePad to open the registration file.
