Winmate R15FA3S-PCC3-PoE Quick Start Manual

S-series hmi ubuntu 16.04
Hide thumbs Also See for R15FA3S-PCC3-PoE:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
15" S-Series HMI
Ubuntu 16.04
R15FA3S-PCC3-PoE
Quick Start Guide
V1.0
For more information on this and
other Winmate products, please
visit our website at:
www.winmate.com
Please read these instructions carefully before using this product, and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R15FA3S-PCC3-PoE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winmate R15FA3S-PCC3-PoE

Summary of Contents for Winmate R15FA3S-PCC3-PoE

  • Page 1 15” S-Series HMI Ubuntu 16.04 R15FA3S-PCC3-PoE Quick Start Guide V1.0 For more information on this and other Winmate products, please visit our website at: www.winmate.com Please read these instructions carefully before using this product, and save this manual for future use.

  • Page 2: Table Of Contents

    VESA Mounting - 26 - SPECIFICATIONS - 34 - APPENDIX - 37 - Appendix A: Cleaning the Monitor - 37 - Appendix B: Winmate Software Development Kit - 38 - Appendix C: Ubuntu Command Code - 39 - - 2 -...

  • Page 3: Fcc Statement

    FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful  interference. This device must accept any interference  received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class "B"...
  • Page 4 European Union Electromagnetic Compatibility Directive (2014/30/EU)  EN55024: 2010/ A1: 2015 o IEC61000-4-2: 2009 o IEC61000-4-3: 2006+A1: 2007+A2: 2010 o IEC61000-4-4: 2012 o IEC61000-4-5: 2014 o IEC61000-4-6: 2014 o IEC61000-4-8: 2010 o IEC61000-4-11: 2004  EN55032: 2012/AC:2013  EN61000-3-2:2014  EN61000-3-3:2013 Low Voltage Directive (2014/35/EU) ...
  • Page 5 Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We...
  • Page 6 Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.

  • Page 7: Safety Information

    Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.

  • Page 8: Introduction

    Congratulations on purchasing Winmate® 15” S-Series HMI. Interactive and smart automation systems of intelligent buildings are in a fast growing phase. Winmate multi-touch S-Series HMI is suitable for home automation and room management systems. Flat surface is easy-to-clean and delivers aesthetically pleasing look for any interior.

  • Page 9: Package Contents

    Package Contents Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: Quick Start Guide Driver CD &...
  • Page 10 Package may include optional accessories based on your order: VESA Wall Mount VESA Desk Stand Bracket LA-100 LA-106 9B0000000128 9B0000000412 - 10 -...

  • Page 11: Product Overview

    Product Overview Unit: mm № Description № Description ① Console Port (for Linux) ⑥ USB 2.0 x 1 ② Micro SD Card Slot ⑦ 12V DC ③ LAN/ PoE ⑧ 1 Watt Speaker ④ USB OTG ⑨ NFC Reader (Optional) ⑤...

  • Page 12: Installation

    INSTALLATION Wiring Requirements The following common safety precautions should be observed before installing any electronic device:  Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point.

  • Page 13: Connecting To Other Devices

    Connecting to Other Devices Power Input Connector The DC power source input of the 7” S-Series HMI is a 2 pin terminal block connector that supports 12V DC power input. Minimum Voltage 11.4V Maximum Voltage 12.6V Voltage Maximum Current 4.2A Serial Port Connector The 7”...
  • Page 14 Ethernet Connector The 7” S-Series HMI supports one RJ45 10/100/1000 Mbps Ethernet interface for connecting to the internet. Signal Signal № № Name Name TX1+ TX1- TX2+ TX2- TX3+ TX3- TX4+ TX4- IMPORTANT: Power Device (PD): IEEE 802.3at (25 W), IEEE 802.3af (15 W) USB OTG Connector Use USB OTG connector to connect the HMI device to other USB On-The-Go compliant devices such as flash drives, digital cameras,...

  • Page 15: Getting Started

    GETTING STARTED Turning On Your Device Follow the following steps to turn on your device: 1. Connect the HMI device to a thermal block (2-pin). 2. Connect the other side of the thermal block to the AC adapter. 3. Connect the AC adapter to the power cord. 4.

  • Page 16: Turning Off Your Device

    Turning Off Your Device To turn off the HMI device: 1. Click the lower right Logout button on the desktop 2. Choose Shut Down option to shut down the HMI device. 3. Disconnect the HMI device from the power source (if necessary).

  • Page 17: Operating The Device

    Ubuntu 16.04 and basic settings. For more advanced Ubuntu settings, please click here to download SDK from Winmate Download Center. Start Menu 1. Click the lower left Start button on the desktop to expand Start Menu.

  • Page 18: Linux Terminal

    Linux Terminal 1. Click on the Start button at the bottom left side of the desktop, in drop-down menu choose System Tools > LXTerminal. 2. You are in Linux Ubuntu terminal. - 18 -...

  • Page 19: System Information

    System Information 1. Open Linux Terminal, enter command code to check OS and CPU information. To find System Information command code, please refer to Appendix of this manual. - 19 -...

  • Page 20: Brightness Adjustment

    Brightness Adjustment 1. Open Linux Terminal, enter command code to change brightness settings. 2. brightness.png -> Use “echo” and “cat” command to control the backlight of the LCD panel. The range is 0 (lowest brightness) to 7 (highest brightness). To find Brightness adjustment command code, please refer to Appendix C of this manual.

  • Page 21: Ethernet Settings

    Ethernet Settings To configure Ethernet Settings, follow the instruction below: 1. Connect Ethernet Cable to the HMI device. 2. Click on the Ethernet connection icon located at the bottom right side of the desktop. Icon Description Ethernet is not connected to the HMI device. Ethernet is connected to the HMI device.
  • Page 22 5. In General menu select “Automatically connect to this network when it is available” and “All users may connect to this network”. 6. Go to Ethernet menu, confirm that MTU is set as automatic and Wake on LAN is chalk marked as Default. - 22 -...
  • Page 23 7. Go to IPv4 Settings menu, tap on Method. If you want to use DHCP, in the Method drop-down menu select Automatic (DHCP). 8. If you want to use Static IP, in the Method drop-down menu select Manual. Then configure your Static IP settings. 9.

  • Page 24: Changing Serial Port Settings

    Changing Serial Port Settings Serial port can be configured for RS-232, RS-422 or RS-485. Please click here to download Winmate® SDK for Ubuntu 16.04. Get Mode Use the Linux command cat to read the value in console. There is no "new line" character after the string "RS-232", so we append ";echo"...

  • Page 25: Exit The System

    Exit the System Click the lower right Logout button on the desktop to logout Linux session. For a more detailed Ubuntu 16.04 user guide, follow the download path below: http://files.ubuntu-manual.org/manuals/getting-started-with- ubuntu/16.04/en_US/screen/Getting%20Started%20with%20Ubuntu%2016.04. - 25 -...

  • Page 26: Mounting

    MOUNTING S-series HMI devices come with different mounting options suitable for most of the industrial and commercial applications. S-series HMI devices come with different mounting options suitable for most of the industrial and commercial applications. Panel Mounting Panel Mount mounting solutions is suitable for many applications where HMI should be embedded in the machine.
  • Page 27 VESA Desk Stand PCVS-V1 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: PCVS-V1 Part Number: 99KK00A0000E Mounting Instruction  Use provided Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device.
  • Page 28 VESA Desk Stand LA-100 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: LA-100 Part Number: 9B0000000128 Mounting Instruction  Use provided Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device.
  • Page 29 VESA Wall Mount Bracket LA-106 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: LA-106 Part Number: 9B0000000412 Mounting Instruction - 29 -...
  • Page 30 Accessories Dimensions - 30 -...
  • Page 31 Front Side Wall Mounting You can purchase Front Side Wall Mount Bracket from Winmate as an optional accessory for 15” S-Series HMI. Model Name: PCFW-V1 Part Number: 99KK00A0000C Dimensions - 31 -...
  • Page 32 Mounting Instruction 1. Cut a hole in the wall according to the cutout dimensions. 2. Attach the bezel with clips to the device; fix the bezel with Philips M4x5 screws. 3. Connect the device to the power source with the power cord. 4.
  • Page 33 Glass Wall Mounting The HMI device can be installed in a glass wall either from right side or from the left. You can purchase Winmate Glass Wall Mount Kit as an optional accessory. Right Side Left Side Model Name: Model Name: PCGM-...

  • Page 34: Specifications

    SPECIFICATIONS HMI Device Specifications Model Name R15FA3S-PCC3-PoE Size 15" TFT (Widescreen) Resolution 1024 x 768 Brightness 250 nits Display Max Colors 262K (6 bit) PCAP Multi-Touch (Supports 5 Touch points) Freescale® Cortex® A9 i.MX6 Dual Core 1GHz (optional Quad Core) System Freescale®...
  • Page 35 Power Input 12V DC Power Power Consumption Management Power over Power Device (PD): follows Ethernet IEEE 802.3at (25 Watt) Dimensions 363.40 x 277.86 x 44.50 mm (W x L x H) VESA Mount (100 x 100 mm), Mounting Mechanical Panel Mount Specifications Cooling Fanless design...
  • Page 36 Supported HF RFID Tag The HF RFID Reader of this device supports the following card type. HF RFID Standard Purpose Standard for MIFARE technology, which used ISO-14443 A in smart cards and proximity cards ISO-15693 Standard for tracking items - 36 -...

  • Page 37: Appendix

    APPENDIX Appendix A: Cleaning the Monitor Before cleaning:  Make sure the device is turned off.  Disconnect the power cable from any AC outlet. When cleaning:  Never spray or pour any liquid directly on the screen or case. ...

  • Page 38: Appendix B: Winmate Software Development Kit

    Appendix B: Winmate Software Development Kit Winmate® provides Software Development Kit (SDK). The table below lists SDK provided by Winmate for E-Series HMI with Freescale® Cortex® A9 i.MX6 Dual Core processor: Item Driver Description Ubuntu SDK Ubuntu SDK To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us.

  • Page 39: Appendix C: Ubuntu Command Code

    Appendix C: Ubuntu Command Code This section contains the code for main commands for Ubuntu. Brightness The source code is located in /sys/class/backlight/backlight.25/brightness We use “sudo sh -c "echo 3 > /sys/class/backlight/backlight.25/brightness”” to set the brightness. The range is between 0 to 7. Use the command “cat /sys/class/backlight/backlight.25/brightness”...
  • Page 40 Serial Port a. Open COM Port // *************************************************************************** Parameter: // static char *portname = "/dev/ttyUSB0"; // static int COMPort_fd; // Baud rate: 115200 // bits per second: 8 // parity: none // stop bits: 1 // *************************************************************************** static void cmd_open(void) COMPort_fd = open (portname, O_RDWR | O_NOCTTY | O_SYNC);...
  • Page 41 c. Read/ Write Command // *************************************************************************** // Parameter: // write_data static char write_data[] = "Hello World!!"; // *************************************************************************** static void cmd_write(void) write(COMPort_fd, &write_data[0], sizeof(write_data)); // send character greeting usleep((sizeof(write_data) + 25) * 100); char buf[200]; n = read(COMPort_fd, buf, sizeof(buf)); // read up to 100 characters if ready to read printf("Read Data =...
  • Page 42 NOTES _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________...
  • Page 43 NOTES _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _____________________________________________________...
  • Page 44 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
