Page 1: User Manual
PAR-18-18W-IP65 18x18W RGBW A+UV 6in1 LED PAR Light for Outdoor use (IP65) USER MANUAL Please read this manual carefully and proper take care of this manual. - Page 2 Dear customer, First of all thanks for purchasing a SOUNDSATION® product. Our mission is to satisfy all possible needs of musical instrument, professional audio and lighting users offering a wide range of products using the latest technologies. We hope you will be satisfied with this item and, if you want to collaborate, we are looking for a feedback from you about the operation of the product and possible im- provements to introduce in the next future.
-
Page 3: Table Of Contents
ENGLISH TABLE OF CONTENTS 1. 1. INTRODUCTION ....................5 1.1. UNPACKING ................................6 1.2. ACCESSORIES ................................6 2. OVERVIEW ........................6 3. MAIN FEATURES ......................6 4. OVERHEAD RIGGING ....................7 5. MAINS CONNECTIONS .....................7 6. DMX CONNECTION ....................7 6.1. DMX Terminator ..............................8 6.2. 3-Pin vs 5-Pin DMX cables ..........................9 7. - Page 4 ENGLISH PAR-18-18W-IP65 User manual IMPORTANT SAFETY SYMBOLS The symbol is used to indicate that some hazardous live terminals are involved within this apparatus, even under the normal operating con- ditions, which may be sufficient to constitute the risk of electric shock or death.
-
Page 5: Introduction
1. INTRODUCTION Thank you for purchasing our PAR-18-18W-IP65 graphic laser. Enjoy your new equip- ment and make sure to read this manual carefully before operation! This user manual is made to provide both an overview of controls, as well as informa- tion on how to use them. -
Page 6: Unpacking
ATTENTION: Packaging bag is not a toy! Keep out of reach of children!!! Keep in a safe place the original packaging material for future use. 1.2. ACCESSORIES SOUNDSATION can supply a wide range of quality accessories that you can use with your PAR-18-18W-IP65, like Cables, Splitters, DMX controllers, and a wide range of fixtures. -
Page 7: Overhead Rigging
ENGLISH PAR-18-18W-IP65 pro User manual 4. OVERHEAD RIGGING WARNING: The installation must be carried out by qualified service personal only. Improper installation can result in serious injuries and /or damage to property. Overhead rigging required extensive experience! Working load limits should be respected, Certified installation materials should be used, the installed device should be inspected regularly for safety. -
Page 8: Dmx Terminator
ENGLISH PAR-18-18W-IP65 User manual DMX Termonator Unit 1 Unit 2 Last Unit DMX 512 Connect fixtures using shielded 2-conductor twisted pair cable with 3-pin XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-), and pin 3 is Data positive (S+). -
Page 9: 3-Pin Vs 5-Pin Dmx Cables
ENGLISH PAR-18-18W-IP65 pro User manual Signal amplifier is a must to connect more fixtures. 6.2. 3-Pin vs 5-Pin DMX cables DMX connection protocols used by controllers and fixtures manufacturers are not stan- dardized around the world. However, two are the most common standards: 5-Pin XLR and 3-Pin XLR system. -
Page 10: Menu Instruction
ENGLISH PAR-18-18W-IP65 User manual MENU enter 6. MENU: Used to select different menu items. 7. UP: To go up in the menu and to increase values shown on the display. 8. DOWN: To go back in the menu and to lower values shown on the display. -
Page 11: Dmx Channel Chart
ENGLISH PAR-18-18W-IP65 pro User manual f Sound mode - 3 built-in Sound modes f Master/Slave mode - When active, the unit controls other PARs connected via DMX cables. To set Master mode please refer to “8. MENU INSTRUCTION” at page 10,... - Page 12 ENGLISH PAR-18-18W-IP65 User manual CH10 (When CH9: 010-050) push CH10 to a static color selection Color change / 000 - 255 (When CH9: 051-200) push CH10 for the additional speed. Speed Speed adjustment changes from slow to fast. (Works with CH9)
-
Page 13: Specifications
ENGLISH PAR-18-18W-IP65 pro User manual 11. SPECIFICATIONS Model PAR-18-18W-IP65 Light source 18 x 18W RGBWA+UV 6IN1 LED Beam angle 25° R 3000 Lux, G 6000 Lux, B 6000 Lux, W12000 Lux, A 3000 Lux @ 1m Lux, UV 2500 Lux, RGBWA+UV 30000 Lux... -
Page 14: Warranty And Service
SOUNDSATION shall satisfy the warranty obligations by remedying any material or manufacturing faults free of charge at SOUNDSATION’s discretion either by repair or by exchanging individual parts or the entire appliance. Any defective parts removed from a product during the course of a warranty claim shall become the property of SOUNDSATION. - Page 15 Questo prodotto viene importato nella UE da FRENEXPORT SPA – Via Enzo Ferrari, 10 - 62017 Porto Recanati - Italy www.soundsa tionmusic.com Soundsation® is a registered trademark of FRENEXPORT SPA - Italy Soundsation® è un marchio di fabbrica registrato della FRENEXPORT SPA - Italy...
- Page 16 www.soundsa tionmusic.com Ver 1.0 - July 2017...
