USER'S MANUAL
MHL-12-12W-RGBW
12*12W RGBW (four in one)
LED Fancy Beam Moving Head Light
Please read this manual carefully and proper take care of this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MHL-12-12W-RGBW and is the answer not in the manual?

Questions and answers

Summary of Contents for soundsation MHL-12-12W-RGBW

  • Page 1 USER'S MANUAL MHL-12-12W-RGBW 12*12W RGBW (four in one) LED Fancy Beam Moving Head Light Please read this manual carefully and proper take care of this manual.
  • Page 2 ENGLISH Dear customer, First of all thanks far purchasing a SOUNDSATION® product. Our mission is to satisfy all possible needs of musical instrument and professional audio users offering a wide range of products using the latest technologies. We hope you will be satisfied with this item and, if you want to collaborate, we are looking for a feedback from you about the operation of the product and www.
  • Page 3: Table Of Contents

    ENGLISH TABLE OF CONTENTS 1. GETTING STARTED ....................5 1.1 Important Safety Symbols ..................5 1.2 Important Safety Instructions ................5 1.3 Introduction ......................7 1.4 Before You Start ....................7 2.1 FUNCTION ......................8 2.2 Machine Connection .....................9 3. REFERENCE ......................10 4. WARRANTY AND SERVICE ..................12 5.
  • Page 4 ENGLISH...
  • Page 5: Getting Started

    ENGLISH 1. GETTING STARTED 1.1 Important Safety Symbols The symbol is used to indicate that some hazardous live termi- nals are involved within this apparatus, even under the normal operating conditions, which may be sufficient to constitute the risk of electric shock or death. The symbol is used in the service documentation to indicate that specific component shall be replaced only by the compo- nent specified in that documentation for safety reasons.
  • Page 6 ENGLISH MHL-12 User’s manual explosive or corrosive materials surrounded in 10 meters while operating. Heat The apparatus should be located away from heat sources such as radiators, stoves or other appliances that produce heat. Fixture may carry high heat, do not aim at objective exceeding 2 minutes.
  • Page 7: Introduction

    Warning Avoid direct eye exposure to the light source while it is on. 1.3 Introduction Thanks for purchasing our MHL-12-12W-RGBW Fancy Beam Moving Head Light. This user manual is made to provide both an overview of the controls, as well as information on how to use them.
  • Page 8: Function

    ENGLISH MHL-12 User’s manual packing materials. If the fixture must be returned to manufacturer, it is impor- tant that the fixture be returned in the original manufacturer box and packing. 1.4.2 Getting started Make sure there is enough space around the unit for proper ventilation and prevent overheating;...
  • Page 9: Machine Connection

    ENGLISH MHL-12 User’s manual 2.2 Machine Connection 2.2.1 Cable Connectors Cables must have a male XLR connector on one end and a female XLR con- nector on the other end. DMX use of XLR connectors 1 = Ground / Shield 2 = DMX + 3 = DMX - OUTPUT...
  • Page 10: Reference

    ENGLISH MHL-12 User’s manual 3. REFERENCE 16 DMX Channels DMX Channel Description: Function Data Function Description Channel 0--255 Tilt 0--255 Tilt Pan Fine 0--255 Pan fine Tilt Fine 0--255 Tilt fine Lens Rotation Speed 0--255 Form fast to slow Lens Rotation 0--255 Lens rotation Dimmer...
  • Page 11 ENGLISH MHL-12 User’s manual Declare This product, which is at the factory, performance in good condition, and completely packed. All users shall strictly comply with the above warnings and instructions, any damage caused by the misuse is not within our company guarantee, to ignore operation manual and cause of the failure and problems which is not in the scope of dealer is responsible for.
  • Page 12: Warranty And Service

    Alternatively you can send the product to SOUNDSATION SERVICE CENTER – Via Enzo Ferrari , 10 – 62017 Porto Recanati - Italy . In order to send a product to ser- vice center you need an RMA number.
  • Page 13: Warning

    WEEE scheme or your household waste disposal service. This product is imported in EU by FRENEXPORT SPA – Via Enzo Ferrari, 10 - 62017 Porto Recanati - Italy www.soundsa tionmusic.com Soundsation® is a registered trademark of FRENEXPORT SPA - Italy...
  • Page 14 www.soundsa tionmusic.com Ver 1.0 - Dec. 2015...
