- Page 1 USER'S MANUAL MHL-230 Beam 230 (7R) moving head light Please read this manual carefully and proper take care of this manual.
- Page 2 ENGLISH Dear customer, First of all thanks far purchasing a SOUNDSATION® product. Our mission is to satisfy all possible needs of musical instrument and professional audio users offering a wide range of products using the latest technologies. We hope you will be satisfied with this item and, if you want to collaborate, we are looking for a feedback from you about the operation of the product and www.
-
Page 3: Table Of Contents
ENGLISH TABLE OF CONTENTS 1. GETTING STARTED ....................4 1.1 Important Safety Symbols ..................4 1.2 Important Safety Instructions ................4 1.3 Important Notes .....................6 1.4 Maintenance and Cleaning ..................8 1.3 Before You Start ....................10 1.4 Introduction ......................10 2. Installation ......................11 2.1 Machine Connection ...................13 2.2 Connection with the Mains .................14 3. -
Page 4: Getting Started
ENGLISH MHL-230 User’s manual 1. GETTING STARTED 1.1 Important Safety Symbols The symbol is used to indicate that some hazardous live termi- nals are involved within this apparatus, even under the normal operating conditions, which may be sufficient to constitute the risk of electric shock or death. - Page 5 ENGLISH MHL-230 User’s manual explosive or corrosive materials surrounded in 10 meters while operating. Heat The apparatus should be located away from heat sources such as radiators, stoves or other appliances that produce heat. Fixture may carry high heat, do not aim at objective exceeding 2 minutes.
-
Page 6: Important Notes
ENGLISH MHL-230 User’s manual DMX connection When use DMX controller, please make sure that there is no interference sources (e.g. intercom, high frequency radio waves and radiation source. Cleaning Clean only with a dry cloth. Do not use any solvents such as benzol or alcohol. - Page 7 ENGLISH MHL-230 User’s manual edges. Check the device and the power cord by the plug. Never pull out the plug by tugging the power-cord. Always disconnect from the mains, when the device is not in use or before cleaning it. Only handle the power cord by the plug. Never pull out the plug by tugging the power-cord.
-
Page 8: Maintenance And Cleaning
ENGLISH MHL-230 User’s manual the result of unprofessional operation. CAUTION! The lamp has to be replaced when it is damaged or deformed due to the heat! Please use the original packing if the device is to be transported. Please consider that unauthorized modifications on the device are forbidden due to safety reasons. - Page 9 ENGLISH MHL-230 User’s manual Danger! High power! Danger to life! Disconnect from mains before starting maintenance operation! We recommend an frequent cleaning of the device. Please use moist flax to clean. Never use alcohol or solvents. CAUTION! The lens has to be replaced when it is obviously damaged, so that its function is impaired, e.g.
-
Page 10: Before You Start
ENGLISH MHL-230 User’s manual 1.3 Before You Start 1.3.1 UNPACKING Carefully unpack the box and check the contents to ensure that all parts are present and in good conditions. If anything damaged during transit, notify the shipper immediately and keep the packing material for inspection. -
Page 11: Installation
ENGLISH MHL-230 User’s manual One gobo wheel with seventeen rotating metal gobos and one glass gobo. High speed rotating 8-facet prism Combined shutter/dimmer unit allowing very smooth dimming and strobe effect 1-10 flash/second The lighting of the stock size Addressing, special functions setting, effects calibration via control panel... - Page 12 ENGLISH MHL-230 User’s manual Do not operate the f ixture with operate hous- ing-cover! The brightness of the lighting has been aligned at the factory. Due to the differ- ence between lamps, fine adjusted may improve light performance. Strike the lighting, open the grating and the diaphragm, adjust the brightness to 100%, then focus the light on a flat surface (e.g.
-
Page 13: Machine Connection
ENGLISH MHL-230 User’s manual IMPORTANT MATTER! Overhead rigging requires extensive experience, including (but not limited to) calculating working load limits, installation material being used, and peri- odic safety inspection of all installation material and the projector. If you lack these qualifications, do not attempt the installation yourself, but instead use a professional structural rigger. -
Page 14: Connection With The Mains
ENGLISH MHL-230 User’s manual DMX use of XLR connectors 1 = Ground / Shield 2 = DMX + 3 = DMX - OUTPUT INPUT A word on termination: DMX is a resilient communication protocol, however errors still occasionally occur. Termination reduces signal errors, and there- fore best practices include use of a terminator in all circumstances. -
Page 15: Dmx Channels
ENGLISH MHL-230 User’s manual DMX-512 Connection/Connection between Fixtures The wires must not come into contact with each other; otherwise the fixtures will not work at all, or will not work properly. 0nly use a stereo-shielded cable and 3-pin XLR-plugs and connectors in order to controller with the fixture or one fixture with anther. - Page 16 ENGLISH MHL-230 User’s manual 35--38 Green 39--42 Green, deep yellow 43--46 Deep yellow 47--51 Deep yellow, magenta 52--55 Magenta 56--59 Magenta, UV 60--63 64--68 UV, CTO 69--72 73--76 CTO, yellow green 77--81 Yellow green 82--85 Yellow green, brown yellow 86--89...
- Page 17 ENGLISH MHL-230 User’s manual 0--2 No brightness 3--103 Form slow to fast 104--107 Strobe stop Strobe 108--207 Form slow to fast, strobe effects 208--212 Strobe stop 213--251 Strobe random 252--255 Strobe stop Dimmer 0--255 From dark to bright Gobo Wheel...
- Page 18 ENGLISH MHL-230 User’s manual 167--172 Gobo2 shaking 173--179 Gobo3 shaking 180--185 Gobo4 shaking 186--192 Gobo5 shaking 193--198 Gobo6 shaking 199--204 Gobo7 shaking 205--211 Gobo8 shaking 212--217 Gobo9 shaking 218--223 Gobo10 shaking 224--230 Gobo11 shaking 231--236 Gobo12 shaking 237--242 Gobo13 shaking...
-
Page 19: Addressing
ENGLISH MHL-230 User’s manual CH15 Reset Renew factory state 0--62 No function CH16 Lamp Off / Lamp On 63--65 Lamp off 178--180 Lamp on 4. Addressing The control board on the front side of the base allows you to assign the DMX fixture the address, which is defined as the first channel. -
Page 20: Technical Specfications
ENGLISH MHL-230 User’s manual 5. Technical Specfications Power Supply: Europe voltage: 208/230/240V AC, 50/60HZ Fuse: T5A, 250V The USA voltage: 100/115/208/230V AC, 50/60HZ Lamp: Osram 7R 230W Fuse: T10A Power consumption: 300W Optical System: High luminous efficiency parabolic mirror and double con-... - Page 21 ENGLISH MHL-230 User’s manual Physical Parameters Dimensions and Weight: Length of base (including handles): 470 Width: 330 mm Height (head horizontal): 440 mm Weight (net weight): 16 kg Shipping weight: 18 kg Our company reserves the right to change technical parameters without notice.
-
Page 22: Warranty And Service
Alternatively you can send the product to SOUNDSATION SERVICE CENTER – Via Enzo Ferrari , 10 – 62017 Porto Recanati - Italy . In order to send a product to ser- vice center you need an RMA number. -
Page 23: Warning
WEEE scheme or your household waste disposal service. This product is imported in EU by FRENEXPORT SPA – Via Enzo Ferrari, 10 - 62017 Porto Recanati - Italy www.soundsa tionmusic.com Soundsation® is a registered trademark of FRENEXPORT SPA - Italy... - Page 24 www.soundsa tionmusic.com Ver 1.0 - Dec. 2015...
