Summary of Contents for Holzhof MAX XM 100 RP line
- Page 1 MAX XM 100 RP line MAX XM 100 RP line MAX XM 100 RP line MAX XM 100 RP line assembly assembly assembly assembly instructions instructions instructions instructions...
-
Page 2: Assembly Sequence
ASSEMBLY SEQUENCE: 1. STRUTS AND PLATFORMS 2. ARCHWAYS 3. PARAPETS 4. SLIDE 5. RAMP 6. BENCH 7. ROOF 8. ATTACHED GYM 9. UNDERGROUND LAYING/ANCHORAGE OF THE STRUCTURE... - Page 3 NOTA BENE: it is recommended to fix the bolts definitively and only insert the caps once the Article fixing CODE N. NAME correct positioning of the elements has been num. verified. xpe11 Shaped PE nut protection cap xpe10 PE nut protection cap xpe116 PE cap ISO7089 Ø8 washer...
- Page 4 NOTA BENE: it is recommended to fix the bolts definitively and only insert the caps once the correct NOTA BENE: it is recommended to fix the bolts definitively and only insert the caps o nce the correct NOTA BENE: it is recommended to fix the bolts definitively and only insert the caps o NOTA BENE: it is recommended to fix the bolts definitively and only insert the caps o nce the correct nce the correct...
- Page 5 NOTA BENE: NOTA BENE: i i i i t is recommended to fix NOTA BENE: NOTA BENE: t is recommended to fix t is recommended to fix t is recommended to fix the bolts definitively and only insert the the bolts definitively and only insert the the bolts definitively and only insert the the bolts definitively and only insert the caps once the correct positioning of the...
- Page 6 1. After having fixed the PE archway (2), place the body of the Article Default/ NAME num. Quantity curved slide (3) on the platform of the tower (1) and insert the bolts, necessary for fixing, into the holes present on the Tower slide (3).
- Page 7 NOTA B E N E : it is recommended to fix the bolts definitively and only insert the caps once the correct positioning of the elements has been verified. 1. Insert the (5) M8x70 threaded bars into the bushes present on the (6) climbing board. Attach the climbing board (6) by introducing the threaded bars (5) into the pre-drilled holes in the platform...
- Page 8 Article Default/ CODE N. NAME num. Quantity PE roof xpe10 PE nut protection cap xpe116 PE cap IS07089 Ø8 washer M8x80 TEL screw NOTE: The models represented are purely indicative. These instructions are applicable to Max, Sultan and Aladin roofs. 1.
- Page 9 1) PE cap (4x) 2) PE nut protection cap (4x) 3) M8 washer (4x) 4) M8x80 (4x) LG* TEL screw 5) M6 3x60 (4x) AL* TEFR screw 6) Assembled bench NOTA BENE: it is NOTA BENE: it is NOTA BENE: it is NOTA BENE: it is recommended to fix the recommended to fix the...
- Page 10 1. Position the climbing net beam (3) in the housing of the pre-assembled climbing ladder (4), inserting the bolts necessary for fixing as in the figure, however without fixing it completely and without positioning the caps. NOTA BENE: it is recommended to fix the * lg: wood * lg: wood * lg: wood...
- Page 11 1) 1) 1) 1) 1 x climbing net strut 1 x climbing net strut 1 x climbing net strut 1 x climbing net strut 2) 2) 2) 2) 1 x rope beam 1 x rope beam 1 x rope beam 1 x rope beam 3) 3) 3) 3) 1 x net beam 1 x net beam...
- Page 12 1. Position the upper part of the climbing net (1), inserting the bolts necessary for fixing into the thimbles as indicated the figure, without fixing it completely and without positioning the caps. 2. Position the climbing rope (6), inserting the bolts necessary for fixing into the thimbles as indicated the figure, without fixing it completely and without positioning the caps.
- Page 13 NOTA BENE: it is recommended to fix the NOTA BENE: it is recommended to fix the NOTA BENE: it is recommended to fix the NOTA BENE: it is recommended to fix the bolts definitively and only insert the caps bolts definitively and only insert the caps bolts definitively and only insert the caps bolts definitively and only insert the caps UNDERGROUND...
- Page 14 Concrete deck rubber safety flooring...
- Page 15 1. Excavate a hole with diameter of 30 cm and depth of 60 cm 2. Cast a first layer of concrete with thickness of 10 cm.
- Page 16 3. When the concrete has set, position the slide bracket in the hole, checking the correct alignment of the lower part of the slide with the finished ground level.
- Page 17 4. Complete concrete casting as per layout. 5. When the concrete has set, fill the excavation hole by compacting the infill material up to the finished ground level.
- Page 18 1. 1. 1. 1. A A A A ttach the brackets (1) by introducing the follo ttach the brackets (1) by introducing the following in wing in ttach the brackets (1) by introducing the follo ttach the brackets (1) by introducing the follo wing in wing in sequence: PE nut protection cap (2), M8 washer (3),...
- Page 19 1. Drill. 2. Clean the hole thoroughly using an air pump and small brushes. 3. Insert the anchor into the hole present on the bracket with the aid of a hammer. 4. Tighten using dynamometric wrench. rubber safety flooring rubber safety flooring rubber safety flooring rubber safety flooring 4 x M10x90 screw anchors...
- Page 20 Article num. Quantity CODE N. NAME xfe265 59x59x35 stainless steel angle bracket xpe10 PE nut protection cap xpe116 PE cap M10 self-locking nut M8x115 screw anchor Ø10 washer 1. Position the slide on the support surface, marking the position of the screw anchor.
- Page 21 Article Quantity CODE N. NAME 1. Position the climbing board on the support surface and num. mark the position of the screw anchors. xpe10 PE nut protection cap 2. 2. Drill the support surface and position the screw xpe116 PE cap anchors.
