  • Page 1 XM-7612 SEATED PREACHER CURL Owner’s Manual 8/09...

  • Page 2: Table Of Contents

    Table Of Contents Important Safety Information Before You Start Assembly Parts List Exploded View Warranty Information...

  • Page 3: Important Safety Information

    SAFETY PRECAUTIONS • This unit should only be used on a level surface and is intended for indoor use only. XMARK Fitness recommends an equipment mat be placed under the unit to protect the floor or carpet and for easier cleaning.

  • Page 4: Before You Start

    This manual will guide you through the assembly process. If at any time you are having trouble with the assembly or use of this product, then please contact us at our XMARK Fitness help line. We have trained service technicians on site to take care of you, our valued customer.

  • Page 5: Assembly

    Assembly...

  • Page 6: Assembly

    Assembly NOTE: Hand tighten bolts and Nylon Lock nuts until machine is fully assembled. Step 1 Connect the Seat Frame (#3) to the Rear Base (#4) and the Weight Support (#1) using: • one M10*90 Button Head Cap Screw (#16) •...
  • Page 7 Assembly NOTE: Hand tighten bolts and Nylon Lock nuts until machine is fully assembled. Step 2 Attach the Support, Telescoping Arm (#2) to the Seat Frame (#3). Attach the Seat Pad (#7) to the Seat Frame (#3) using: • two M10*80 Button Head Cap Screw (#17) •...

  • Page 8: Parts List

    Parts List XM-7612 Parts List Ref # Part # Description P00316 Weight Support, XM-7612 P00317 Support, Telescoping Arm XM-7612 P00318 Seat Frame, XM-7612 P00319 Rear Base, XM-7612 P00203 Pop Pin XM Series P00519 Rubber Pad P00066 Seat Pad, XM-7612 P00067 Pad, Arm Curl XM-7612 Foot Cap, Right 50.8 XM Series...

  • Page 9: Exploded View

    Exploded View...

  • Page 10: Warranty Information

    XMARK Fitness 7501 Trammel Drive Shreveport, LA 71108 Customer Service: 1-800-719-4605...
