- Page 1 XM-4360 ADJUSTABLE AB BENCH Owner's Manual !CAUTION Read all precautions and instructions in this manual before using this equipment.
- Page 2 Table of Contents Before You Begin Important Safety Information Asse mbly Exploded View Parts List...
- Page 3 This manual will guide you through the assembly process. If at any time you are having trouble with the assembly or use of this product, then please contact us at our XMARK Fitness help line. We have trained service technicians on-site to take care of you, our valued customer.
-
Page 4: Important Safety Information
SAFETY PRECAUTIONS ‡ This unit should only be used on a level surface and is intended for indoor use only. XMARK Fitness recommends an equipment mat be placed under the unit to protect the floor or carpet. ‡ Wear comfortable, good-quality walking or running shoes and appropriate cloth- ing. -
Page 5: Parts List
PARTS LIST NUMBER DESCRIPTION QUANTITY FRONT SUPPORT MAIN FRAME BACK SEAT CUSHION FOAM TUBE BOTTOM SUPPORT BACK SEAT CUSHION SUPPORT FOAM ROLLER (WITH JACKET) FAST PIN SCREW M10*75 + TWO WASHERS + NUT SCREW M10*65 + TWO WASHERS + NUT SCREW M10*20 + WASHER SCREW M6*20 + WASHER SECURING CAP... - Page 6 NOTICE: Hand tighten all bolts until fully assembled STEP 01 1、 Attach part (2) to part (5) with bolt assembly (10) and bolt assembly (11). STEP 02 1、 Attach part (1) to another part (5) with bolt assembly (10) and bolt assembly (11).
- Page 7 STEP 03 1、 Attach part (2) to part (1) with part (8). 2、 Attach bolt assembly (10) to part (1). 3、 Attach two parts (4) to part (2), and attach four parts (7) and four parts (13) to part (4). STEP 04 1、...
