Placement and Maintenance
Your Olis Console is designed for indoor use on level floors.
Clean wood veneer and steel parts with a moist cloth.
Olis is engineered for easy assembly. Carefully follow this procedure
to prevent any damage. Do not use power tools for assembly of this
product.
Step 1
Unpack and identify the parts listed below. The assembly workspace
should be a non-marring surface such as carpet. For missing
hardware pieces, contact BDI Customer Service at:
customerservice@bdiusa.com.
For all other concerns, please contact your BDI retailer.
C5 Right Door Pull x 1
C4 Left Door
Pull x 1
C1 Cross Bar x 1
Designed by BDI Studio.
These distinctive product configurations are protected by US and international patents, trade dress, and/or
copyright laws. Olis & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2017, BDI
Made in China. 08.08.2017 V1
OLIS
9650
™
2 DOOR CONSOLE
bdiusa.com
customerservice@bdiusa.com
T1 Phillips Screwdriver x 1
T2 Hex Wrench x 1
H1 1/4-20 x 25 mm FH
Machine Screw x 4
H2 1/4-20 x 15 mm
Machine Screw x 10
H3 #6 x 5/8" Flathead
Wood Screw x 4
C3 Curved Back Panels x 2
A1 Cabinet x 1
C2 Leg Frame x 2
