  • Page 1 HIGH PERFORMANCE FURNITURE FOR YOUR HOME THEATER Odeon 9940 Assembly Instructions...
  • Page 2 Unpack and identify the parts listed on this page. The assembly workspace should be a non-marring surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at: customerservice@bdiusa.com For all other concerns please contact your local BDI Retailer.
  • Page 3 Step 2 Install Handle (F) to flip-down door using Phillips Screwdriver (R) and Handle Screw (K). K x 2...
  • Page 4 Step 3 Turn Cabinet (H) on its backside. With door fully opened, install Base Assembly (T) and Wood Leg (G) using Medium Hex Screw (L) and Hex Driver (S). L x 6 T x 2...
  • Page 5 Step 4 Install Vertical Tube (A) to Cabinet (H) by lowering tube through grommets (pre-installed). Step 5 Attach Vertical Tube (A) to bottom shelf of Cabinet using Long Hex Screw (M), Washer (M2) and Hex Drive. Install Insert Pin (N) to rear side of Vertical Tube using Phillips Screwdriver.
  • Page 6 Step 6 Install Tube Bracket (E) to rear side of cabinet using Hex Driver (S) and Machine Screw (Q). Q x 2 Step 7 Install Back Panel (D) to rear side of cabinet. D x 2...
  • Page 7 Step 8 Attach Upper Bracket (B) to upper portion of Vertical Tube (A) as shown below. Using Hex Driver (S), install Button Screws (J). J x 4 Step 9 Attach Lower Bracket (C) to lower portion of Vertical Tube (A) using Hex Driver (S) and Button Screw (J).
