Placement and Maintenance
Sequel™ Home Office Furniture is designed for indoor use on level floors. Clean glass with
glass cleaner, and steel parts and wood veneer with a moist cloth. Your Sequel™ Home
Office Furniture is engineered for easy assembly. Carefully follow this procedure to prevent
any damage.
Do not use power tools for assembly of this product.
Step 1
Unpack and identify the parts listed below. The assembly workspace should be a non-
marring surface such as carpet. For missing hardware pieces, please contact BDI Customer
Service at customerservice@bdiusa.com. For all other concerns, please contact your BDI
Retailer.
Component List
N - Upper Horizontal Beam x 1
C - Back Panel x 1
E - Lower Horizontal Beam x 1
Designed by Matthew Weatherly.
'Sequel' is a trademark of Becker Designed, Inc.
All rights reserved. ©2014 Becker Designed, Inc.
Made in Taiwan. 6001REV082115v10
sequel
®
6001
desk
F - 4mm Hex Wrench x 1
I - Adhesive Foam/Magnet x 4
Pre-installed on Upper
Horizontal Beam (N)
a s s e m b l y i n s t r u c t i o n s
bdiusa.com
B - Top Glass x 1
-
K
Left Leg x 1
1
customerservice@bdiusa.com
-
L
Right Leg x 1
A - Drawer Assembly x 1
D - Front Kick Panel x 1
G - 1/4-20 x 63 mm Screw x 7
H - 1/4-20 x 12 mm Screw x 16
M - Glides x 4
J - Center Drawer Liner x 2
6001
Advertisement
Table of Contents
Related Manuals for BDI sequel 6001 Desk
Summary of Contents for BDI sequel 6001 Desk
- Page 1 Step 1 Unpack and identify the parts listed below. The assembly workspace should be a non- marring surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. For all other concerns, please contact your BDI Retailer.
- Page 2 Step 1 Install Glides (M) to the bottom of Left Leg (K) and Right Leg (L). M x 4 sequel a s s e m b l y i n s t r u c t i o n s ®...
- Page 3 Step 2 Attach Left Leg (K) to Drawer Assembly (A) using Screw (H) and Hex Wrench (F). Step 3 Attach Right Leg (L) to Drawer Assembly (A) using Screw (H) and Hex Wrench (F). sequel a s s e m b l y i n s t r u c t i o n s ®...
- Page 4 Step 4 Attach Upper Horizontal Beam (N) to inside of Left and Right Leg using Screw (H) and Hex Wrench (F). sequel a s s e m b l y i n s t r u c t i o n s ®...
- Page 5 Step 5 2 Person Task Attach Lower Horizontal Beam (E) to inside of Left and Right Leg using Screw (H) and Hex Wrench (F). sequel a s s e m b l y i n s t r u c t i o n s ®...
- Page 6 2 Person Task Step 6 With the help of another person, gently lower Assembly onto Top Glass (B). Both parts will be placed upside down for the assembly process and fasten into place using Screw (G) and Hex Wrench (F) at all (7) fastener locations.
- Page 7 Step 7 (optional) Attach Magnets to AC power strip/surge protector Remove Adhesive Foam/Magnets (I) from the Upper Horizontal Beam (N). Peel film from side of the Adhesive Foam/Magnets (I) and attach to clean, dry back side of AC power strip (not included). Cleaning of power strip surface with rubbing alcohol will ensure best adhesive bond.
- Page 8 J x 1 With the grippy side facing down, insert Center Drawer Liner (J) into the center drawer. Step 11 Place Sequel Desk in desired location. Once all of the electrical wires are routed, install Kick Panel (D) as shown above. The rear side of panel has magnets that will hold the panel in place.
