New Hallingford - 3 Door Sliding Robe
Assembly Instructions
Dimensions
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
03456 400 800
- Please keep for future reference
Dimensions
Width - 174,6cm
Depth - 60,3cm
Height -205,7cm
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
2687249
2274463
2572048
2285665
2666387
Issue 1 - 11-06-2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Argos 2687249
Summary of Contents for Argos 2687249
- Page 1 New Hallingford - 3 Door Sliding Robe Assembly Instructions 2687249 - Please keep for future reference 2274463 2572048 2285665 2666387 Tip : To prevent damage, we recommend that you build your unit on the carton(s) it was packed in. Dimensions...
- Page 2 Safety and Care Advice Importa Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on •To reduce the likelihood of components and tools listed on the product, this could cause damaging your pages 2 and 3.
- Page 3 Components - Panels Components - Panels Please check you have all the panels listed below Please check you have all the panels listed below Slide door x2 Left side Left side Right side Slide door x2 Right side Upright Upright Shelf Shelf (196.3 x 58cm)
-
Page 4: Tools Required
Components - Fittings If you have damaged or missing components, 0345 6400800 call the Customer Helpline: Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more FK1324 FK1051 FK1056... - Page 5 Assembly Instructions Step Step 1 Insert fittings Attach hanger rail support using 12.5mm screw onto upright Put shelf supports into upright where shown. Flip pannel Attach hanger rail support using 12.5mm screw onto upright Screw locking screw into upright Note: locking screw as far as shown.
- Page 6 Assembly Instructions Step 3 Step Step Insert fittings Insert expando housings into top Flip panel Carefully knock sliding rail into top by using a hammer. Insert locking screw into top Repeat b and c for bottom...
- Page 7 Assembly Instructions Step 4 Attaching panel Position top onto upright Insert twister cam into upright where shown. Usa a screwdriver to turn twister cam clockwise to lock. Temporary support Step 5 Attaching plinths Align the sides of plinth front with bottom shown and attach using chipboardscrew Note: there are no...
- Page 8 Assembly Instructions Step 7 Insert fittings Screw locking screw into right side where shown. Note: Insert locking screw as far as shown. Do not overtighten. Attach hanger rail support using pozi screw onto right side. Insert shelf supports where shown. Step 8 Attaching panel Position right side...
- Page 9 Assembly Instructions Step 10 Attaching panel Position left side onto , large horizontal and bottom Insert twister cam into , large horizontal and bottom where shown Use a screwdriver to turn locking nuts clockwise to lock. Step 11 A:A = B:B Fitting back panels Important! Cabinet MUST...
- Page 10 Assembly Instructions Step 12 Step Step Align the unit Stand up the unit Use a spirit level to check if the base of this unit is level front-to-back , side-to-side and top-to-bottom in the three positions shown. Use pegs to level your unit in all three direction shown.
- Page 11 Assembly Instructions Step 13 Step Step 1 Insert shelf Position shelf onto shelf supports and fix by screwing four chipsboard- screws through shelf supports into shelf Step 14 Inserting hanger rails Place hanger rails onto hanger rail supports...
-
Page 12: Glass Handle With Care
Assembly Instructions GLASS handle with care Step 15 Step Step Fitting handle to door Hold hande mouldings against front of mirror slide door , make sure the ends are flush with one end of the mirror slide door Screw screws into the ‘V’... -
Page 13: Right Hand Door
Assembly Instructions Step 18 Step Step Insert fittings Insert Sliding door rollers in slide doors on the side of the handle mouldings on the end which is flush with This will be the the handle mouldings Right Hand Door Insert sliding door roller adjustables in slide door flush... - Page 14 Assembly Instructions Step 20 Step Step Insert fittings Screw expanding dowel into plinth top Step 21 Attaching plinth Position the plinth top above the unit and slot expanding dowels into the expando housing The top of the plinth top must be flush with the top of the unit.
- Page 15 Assembly Instructions Step 23 Step Step Attaching L-bracket Position L-Bracket onto top as shown, fix by using 15mm screw Note: there are no pre-drilled holes for 15mm screw to fix on the wall, please see last page for more information. Step 24 Attaching door-stops Stick 2 door-stops...
- Page 16 Assembly Instructions If your doors do not run smoothly Level & square the unit Level & square the unit up: Knock the pegs as far as you require, under the ends of the unit and then snap off flush with the panel. For more detailed information see step 12.
-
Page 17: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
