Baby Amelie-
3 Drawer Chest
Assembly Instructions
- Please keep for future reference
228/2785
Dimensions
Width - 80 cm
Depth - 40 cm
Height - 80 cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
Customer Helpline: 08456 400 800
Issue 1 - 24/04/14
Advertisement
Related Manuals for Argos Baby Amelie 228/2785
Summary of Contents for Argos Baby Amelie 228/2785
- Page 1 Baby Amelie- 3 Drawer Chest Assembly Instructions - Please keep for future reference 228/2785 Dimensions Width - 80 cm Depth - 40 cm Height - 80 cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800 Issue 1 - 24/04/14...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly . Check you have all the This product has been produced We do not components and tools listed on from natural timber; you may recommend the pages 2 and 3. - Page 3 Components - Panels Please check you have all the panels listed below 15 Back panel x 2 (57.7x35.8 cm) 16 H profile x 1 (55x1.7 cm)
-
Page 4: Tools Required
Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 Assembly Instructions Step 1 Fitting Wooden Dowels: Insert dowels into holes in the indicated parts. Fitting metal dowel Screw metal dowel into top panel , side panels Note: Insert metal dowels as far as shown. Do not over tighten. Step 2 2 3 4 Parts are labelled for easier...
- Page 6 Assembly Instructions Step 3 Fixing runners: Fix runners in the pre drilled holes on side panel using screws Attention: Make sure runners are positioned as shown. Step 4 Assembly the cabinet Fit bottom frame and back rail to the right side panel as shown.
- Page 7 Assembly Instructions Step 5 Fit left side panel to bottom frame and back rail shown. Insert 2 locking nuts into bottom frame and back rail where shown. Use a screwdriver to turn locking nuts clockwise to lock. Do not over tighten. Step 6 Fit top panel to left side...
- Page 8 Assembly Instructions Step 7 Drawer assembly A) Attach drawer sides in the drawer front using Finished side screws to face inside B) Slide drawer bottom in to slots on drawer sides Make sure finished side face inside the drawer. C) Attach drawer back drawer sides using screws...
- Page 9 Assembly Instructions Step 8 Fixing back panels Carefully turn the chest upright. Fix back panels within rebates using nails . Ensure H profile is in place before nailing as shown. Important: Cabinet MUST be 'square' when back is attached. Step 9 Insert drawers Hook the wheels of the runner on the back of the drawers over...
- Page 10 Assembly Instructions Step 10 Adjusting drawers Loosen the screws in the runners, adjust the drawers to suit and once drawers are aligned retighten and insert 1 screw into fifth hole of the runners Step 11 Adjusting drawers To move drawers left or right: loosen the screws in the runners, adjust the drawers to suit and once drawers are...
- Page 11 Assembly Instructions Step 12 Fixing wall strap Fix strap to top of furniture using washer and screw With help, move furniture into position. Lift with care Mark fixing hole on wall and remove furniture. Drill hole and insert wall plug (not supplied). Warning: Before drilling check wall hidden...
- Page 12 A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
