Introduction

Package contents

1. IPC3 computer
2. Power supply: input 100-240VAC 50/60Hz, 60W output 12VDC@5A, DC plug lock
3. AC cord
4. HDMI to DVI adapter
5. Audio 3.5mm to RCA cable
6. 2 WiFi antennas (in some models)
7. Mini-serial to DB9-female adapter cable
To use IPC3, you will need:

A display with DVI, HDMI or DisplayPort input + DVI, HDMI or DisplayPort cable

USB keyboard and mouse
Hardware specifications
Processor
Type
Cores
Clock speed
TDP
Chipset
Memory
Supported
Storage
Supported
Graphics
GPU
Display Interface 1
Display Interface 2
Display Interface 3
Audio
Codec
Audio Output
Audio Input
Networking
LAN
Wireless (optional)
http://www.fit-pc.com
Tel: +972-48-290-168 | Fax: +972-48-325-251 | www.fit-iot.com
Intel Core 7 Gen i7-7500U/i5-7200U
th
64-bit dual core
2.5-2.7GHz (turbo boost up to 3.1-4.0GHz) (depends on CPU)
15W
Intel 100 Series Mobile PCH (MCP)
2x SO-DIMM 204-pin DDR4 SDRAM memory slots
Up to 32GB (2x 16GB) Non-ECC DDR4-2133
1x SATA up to 6 Gbps (SATA 3.0) for internal 2.5" HDD/SSD
1x M.2 M-key 2280 slot (NVMe 2x PCIe | SATA 3 6 Gbps)
Intel HD 620 Graphics
Dual display mode supported
HDMI 1.4 up to 4096 x 2304 @ 24 Hz
DisplayPort 1.2 up to 4096 x 2304 @ 60 Hz
DisplayPort 1.2 up to 4096 x 2304 @ 60 Hz (mini-DP)
Realtek ALC886 HD audio codec
Analog stereo output, Digital 7.1+2 channels S/PDIF output
3.5mm jack
Analog stereo Microphone input
Digital S/PDIF input
3.5mm jack
2x GbE LAN ports
LAN1: Intel I219 GbE PHY (MAC integrated into the chipset) (RJ-45)
LAN2: Intel I211 GbE controller (RJ-45)
WLAN 802.11ac (2.4/5GHz
5GHz channel availability depends on regulations of Country where IPC3 is used
*
Page 3 of 15
Hayetsira St. 17, Yokneam, Israel
dual band) + Bluetooth 4.0
*
