1. Introduction
The 24-Port 100/10M N-Way Rack-Mount Smart Switch is the latest design in its N-Way
Switches series for easy installation and high-performance in an environment where traffic on the
network and the number of users increase continuously. Provide 24-Port 100/10M Ethernet Switch
support Auto MDI/MDI-X.
of 100Mbps Fast Ethernet performance and preserve existing desktop investment with no changes
required to PCs, NICs, cabling,drivers, or PC configurations.
1.1 Feature and Benefit
Feature
1. Provide 24-Port 100/10M Ethernet Switch to
2. Provide one fiber slide-in port
3. Provide back-pressure
4. Store-and-forward switching scheme capability supports rate adaptation and ensures data
integrity
5. N-way Auto-negotiation on
(100/10Mbps) and auto-detecting mode
you with automatic and flexible solutions in your network connections
6. Auto-polarity detection for correction of incorrect polarity on the received twisted-pair
7. Data fowarding rate
8. Data filtering rate eliminates all error packets, runts, etc. at
speed
9. Conform to IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX /FX, and IEEE 802.3x
flow control for full-duplex standards
10. Provide non-blocking twenty-four ports
11. Support one fiber slide-in port for expansion with the 24th port
12. Full/half-duplex mode operation on all ports
13. Auto-negotiation capability
14. Source address learning and aging function
15. Provide 8K MAC address and
16. LEDs to indicate Power, link/activity, full-duplex/collision, and 100 status
17. Support up to 32 VLAN groups for port pased VLAN.
Small businesses and corporate branch offices can take full advantage
for expansion the workgroup distance to
in half-duplex and flow control in full-duplex
each RJ-45
(full-duplex or half-duplex)
148,800 pps per port at 100% of wire-speed
2.5Mbits SSRAM buffer
support Auto MDI/MDI-X
port. This allows for auto-sensing of speed
148,800pps per port
full-wire speed access
4
2,000 meters
thereby providing
at 100% of wire
