Page 1: User Guide
24-Port 10/100M Ethernet Rack-Mount Switch With Fiber Support User Guide #482824DXFSZ1... - Page 2 FCC Statement This equipment can generate, use and radiate radio frequency energy and, if not installed and used in accordance with the instructions in this manual, may cause interference to radio communications. This equipment has been tested and found to comply with the limits for a Class A computing device pursuant to Part 15 of the FCC rules, which are designed to provide reasonable protection against radio interference when operated in a commercial environment.
-
Page 3: Table Of Contents
Contents 1:Introduction ……………………………………… 4 1.1 Feature & Benefit ………………………… 4 1.2 Technical Specification …………………… 6 1.3 Package Contents ………………………… 7 1.4 Glossary …………………………………… 7 2: Hardware Installation ………………………… 10 2.1 Overview…………………………………… 10 2.2 Hardware Connection ……………………… 12 3: Using Configuration Menu …………………… 14 3.1 Software Installation ………………………... -
Page 4: 1:Introduction
1. Introduction The 24-Port 100/10M N-Way Rack-Mount Smart Switch is the latest design in its N-Way Switches series for easy installation and high-performance in an environment where traffic on the network and the number of users increase continuously. Provide 24-Port 100/10M Ethernet Switch support Auto MDI/MDI-X. - Page 5 Benefit Fiber Slide-in Slot The Switch has fiber. With fiber the workgroup distance could beextended to 2,000 meters and solve the distance limit. Full/Half-Duplex and Easy Expansion The Switch supports both full/half-duplex on all ports which are able to provide 200Mbps of bandwidth to the connected devices using auto-negotiation.
-
Page 6: Technical Specification
1.2 Technical Specification Stan d ard s: IEEE 8 0 2 .3 1 0 BA SE-T Eth ern et IEEE 8 0 2 .3 u 1 0 0 BA SE-TX /FX Fast Eth ern et A N SI/IEEE Std 8 0 2 .3 N -w ay au to -n eg o tiatio n IEEE 8 0 2 .3 M A C lay er fram e size:6 4 -1 5 3 6 By tes IEEE 8 0 2 .3 x flo w co n tro l fo r Fu ll-D u p lex Pro to co l:... -
Page 7: Package Contents
1.3 Package Contents 1.One 24-Port 100/10M N-Way Rack-Mount Smart Switch 2.One Power Cord 3.Two Mounting Brackets 4.One CD-ROM including User Manual Note: If any item is damaged or missing, please contact your supplier. 1.4 Glossary 10BASE-T IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of Category 3, 4, or 5 UTP cable. -
Page 8: Port Mirroring
CSMA/CD Carrier Sense Multiple Access/Collision Detect is the communication method employed by Ethernet and Fast Ethernet. Full Duplex Transmission method that allows switch and network card to transmit and receive concurrently, effectively doubling the bandwidth of that link. Port Trunk Defines a network link aggregation and trunking method which specifies how to create a... - Page 9 IGMP Snooping Listening to IGMP Query and IGMP Report packets transferred between IP Multicast Routers IP Multicast host groups to identify IP Multicast group members. Internet Group Management Protocol (IGMP) A protocol through which hosts can register with their local router for multicast services. If there is more than one multicast router on a given subnetwork, one of the routers is made the “querier”...
-
Page 10: 2: Hardware Installation
2. Hardware Installation This chapter describes the front panel, LED indicators, and rear panel on the Switch. 2.1 Overview Front Panel (24) 24*10/100Mbps RJ-45 Ports - Uses these twenty-four ports to connect to another Switches or Hubs. Each portuses auto-negotiation for automatic speed and mode selection. Fiber Module Slot - Extends the workgroup distance up to 2,000 meters.(Option) Rear Panel... - Page 11 LED Indicators The LED indicators are all located on the front panel which include one Power per device, one Link/Act., one FDX/Col, and one 100 indicator per port. Color Status Description Power Green Lights to indicate the switch is power on. Link/Act Green Lights to indicate a functional network link through...
-
Page 12: Hardware Connection
2.2 Hardware Connection Power The power receptacle is located on the rear panel of the switch. The standard power receptacle is for the AC power cord. RJ-45 Ports 1 2 5 6 7 8 9 1 0 11 12 23 24 The Switch contains 24 10BASE-T / 100BASE-TX RJ-45 ports. - Page 13 Connecting to Switch or Hub You can also connect any RJ-45 station port on the Switch to the Uplink port of a Hub or any port of another switch via straight cable with RJ-45 plugs at both ends. When a attached 10BASE-T/100BASE-TX Hub is powered on or reset: 5 Cab e (10BASE-T Hub) 5 9 1 0...
-
Page 14: 3: Using Configuration Menu
3. Using Configuration Menu The Remote Control Protocol (RRCP) is a simple control protocol proposed to enhance the functionalities of this Layer 2 switches by software. The RRCP Management Application, is a Window-based software package that implements RRCP functions at the management host side. RRCP Management Application gives network administrators the ability to configure and monitor switches like intelligent switches. -
Page 15: Status
3.3 Status After entering RRCP program, the following screen will be shown up. The Management Application shows one switch’s information at one time. You can select a switch using the pull down menu – “Select Switch Mac” which displayed switches discovered in the network. -
Page 16: Overview
3.3.1 Overview Discover Device Information List all switches founded in the network. You can named the switches by double-click the item in the list box. Network topology link vector Show the link status of the switches. Update button You can click it to get the latest information of the connected switches on the network. Switch database button The switch database screen displays “switch’s... -
Page 17: Port Status
3.3.2 Port Status Select the “Port Status” sheet. You can check each port’s link status and configration information in this sheet. Click “Refresh” to get the latest information. -
Page 18: Mib Counter
3.3.3 MIB Counter Select the “MIB Counter” sheet. You can view the counter about the RX, TX Diagnostic Counter. Click the Diagnostic Counter column header, there are three objects you can select, such as Drop count, CRC error count and Collision count. Byte Count button Showing the each port’s amounts of bytes are sent and received. - Page 19 Clear Counter button – Click “Clear Counter” to clear all MIB counters, it will reset the counters to zero. Polling Interval – You can set the time period to count by click “Polling Interval”. The Maximum Time setting is “1410065407” seconds and minimum is “6”...
-
Page 20: Configuration
3.4 Configuration 3.4.1 Port Configuration On the “Port Configuration” sheet, you can check each port’s configuration information including port enable/disable, Tx/Rx bandwidth setting, full/half-duplex, flow control, trunk setting. Note: There will not have port G1 and G2 if you use 24-Port 10/100M Ethernet Rack-Mount Switch With Fiber Support Click “Config”... - Page 21 Tx Bandwidth control Use pull down menu to select the transmission bandwidth you’d like to give. There are 8 options to choose – no, 128Kbps, 256Kbps, 512Kbps, 1Mbps, 2Mbps, 4Mbps, 8Mbps. default setting is no. Rx bandwidth control Use pull down menu to select the receiving bandwidth you’d like to give. There are 8 options to choose –...
- Page 22 Enable Trunking Mark the items which you want to set port trunks. Note: There will not have port G1 and G2 if you use 24-Port 10/100M Ethernet Rack-Mount Switch With Fiber Support...
-
Page 23: Cobal Configuration
3.4.2 Clobal Configuration Global Configuration is used to configure the global port control registers. Press the Refresh button to read the status of the registers. Press the Update button to set the registers as shown in this frame. Half-duplex back pressure flow control Mark Enable/Disable to enable/disable this function. -
Page 24: Qos Configuration
3.4.3 QoS Configuration Qos Configuration is used to configure the control registers. Press the Refresh button to read the status of the registers. Press the Update button to set the registers. There are three options in Configuration and two options in priority queue. You can enable/disable these functions via marking the columns. - Page 25 (Network Control:) 11x000 Low priority: whose DS-field = others values. 802.1p priority When 802.1p tag priority is applied, the switch can recognize the 802.1Q VLAN tag frames and extract the 3-bit User_Priority information from the VLAN tag. The default setting of the threshold of User_Priority is 3.
-
Page 26: Vlan Configuration
3.4.4 VLAN Configuration This sheet allows you to set the VLANs. This switch supports Port-based and Tag-based VLANs. Press the Refresh button to read the status of the registers. Press the Add VLAN/Edit VLAN/Delete VLAN button and select one VLAN in the list box or double-click the VLAN want to configure, it will pop up a dialog like following to set the... - Page 27 TAG Control button Press this button you will see a dialog like following. To configure a port, please double-click the port you want to configure. There are three types of VLAN Tag Control for you to choose: 1.Remove the VLAN tag from all tagged frame.
-
Page 28: Vlan Control
Save VLAN button When finishing VLAN settings, don’t forget to click “Save VLAN” button to save the configuration. 3.4.5 VLAN Control This sheet is to set VLAN Control Registers. Press the Refresh button to read the VLAN control registers. Press the Update button to set the registers, and it will set all VLAN control registers to the selection. - Page 29 ARP broadcast Packet Inter-VLAN The packets with ARP frame will broadcast to all switch ports, if enable this function. IP Multicast Packet Inter-VLAN This function is to enable IP multicast packet to be flood to all the multicast address group member set and the VLAN member set domain limitation will be ignored.
-
Page 30: Device Features
3.4.6 Device Features Setting IGMP Snooping Control register IP Multicast Router Port Discovery register. Router port report will show the IP multicast Router port list. Press the Refresh button to read the register. Press the Update button to set the registers, and it will set the register to the selection. -
Page 31: Security
3.5 Security This page displays the authentication key of the switch, and the RRCP Management Security Mask Configuration. The authentication key is readable. You can press the Refresh button to read the register, and press the Update button to set the registers, and it will set the register to your selection. -
Page 32: Diagnostic
3.6 Diagnostic 3.6.1 Fault Information This page shows some information likes Trunk Port Fault, Network Loop Fault Test. Note: There will be no GigaPHY 1/2 information if you use 24-Port 10/100M Ethernet Rack-Mount Switch With Fiber Support... -
Page 33: Device Reset
3.6.2 Device Reset Click “Restart Switch” to reset the system to the initial state. The MAC table and VLAN table data will be kept. All the current user configured values of internal registers will be kept. The EEPROM download will be done again. -
Page 34: Script
3.6.3 Script This page is for system manufacture using only. -
Page 35: System Menu
3.7 System Menu 3.7.1 Save and Load Configuration You can save or load the configuration to a file. To save a file In the Browser, click System | Save Configuration. To load a file In the Browser, click System | Load Configuration. And in the Open File dialog box, select a “.rrcp”... -
Page 36: Option
3.7.2 Option Hello Polling Select Option | Hello Polling to set the time interval. Counter Polling Select Option | Counter Polling to set the time interval. Authentication Key System will automatically generate the authentication key. The authentication key can not be changed manually. -
Page 37: Help
3.7.3 Help About RRCP You can check the RRCP software’s version here.
