Surecom 824DXFS2B User Manual page 11

LED Indicators
The LED indicators are all located on the front panel which include
Link/Act., one FDX/Col, and one 100 indicator per port.
LED Color
Power Green
Link/Act Green
FDX/COL Green
100 Green
Status Description
On Lights to indicate the switch is power on.
On Lights to indicate a functional network link through
the corresponding port with an attached device.
Flashing Blinks to indicate that the router is actively sending or
receiving data over that port.
On Lights to indicate that the connected port is under
Full-Duplex mode.
Off Off to indicate that the connected port is under
Half-Duplex mode.
Flashing Blinks to indicate that the connected port is under
collision status.
On Lights for any port to indicate that the port is
operating at 100 Mbps.
Off Off to indicate that the port is operating at 10 Mbps
while the network is still operating.
