2. Hardware Installation
This chapter describes the
2.1 Overview
Front Panel
24*10/100Mbps RJ-45 Ports
Each portuses auto-negotiation for automatic speed and mode selection.
Fiber Module Slot
- Extends the workgroup distance up to 2,000 meters.(Option)
Rear Panel
front panel, LED indicators, and rear panel on the Switch.
13
14
15
- Uses these twenty-four ports to connect to another Switches or Hubs.
16
17
18
19
20
21
22
5
6
7
8
9
10
10
23
(24)
12
11
90~264VAC
47~63Hz
