Tx Bandwidth control
Use pull down menu to select the transmission bandwidth you'd like to give. There are 8
options to choose – no,
default setting is no.
Rx bandwidth control
Use pull down menu to select the receiving bandwidth you'd like to give. There are 8 options to
choose – no, 128Kbps, 256Kbps, 512Kbps, 1Mbps, 2Mbps, 4Mbps, 8Mbps.
setting is no.
Speed Advertise
Use pull down menu to select the speed type. There are 4 options to choose – 10Mbps and
Half-duplex, 10Mbps and Full-duplex, 100Mbps and Half-duplex, 100Mbps and Full-duplex.
Note: The default setting is Auto-Negotiation. That means the switch will auto select its
Optimum operational mode based on the capabilities of the node to which it is connected.
Pause Flow Control
None – Mark this column to enable flow control.
Asymmetric to Link Partner
which it is connected.
Symmetric – Mark this item to make the flow control start if the node to which it is connected
enable flow control function.
Asymmetric to Local Device
which it is connected enable flow control function.
128Kbps, 256Kbps, 512Kbps, 1Mbps, 2Mbps, 4Mbps, 8Mbps.
– Mark this item to force the flow control stop of the node to
– Mark this item to make the flow control start if the node to
21
The
The default
