Summary of Contents for Gold Medal Econo-Floss
- Page 1 Instruction Manual Econo-Floss Floss-Maxx Model No. 3017, 3017SR, 3017SS, 3077 and 3077C 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA Part No. 42131...
-
Page 2: Safety Precautions
Econo-Floss Model No. 3017, 3017SR, 3017SS, Floss-Maxx 3077, and 3077C SAFETY PRECAUTIONS www.gmpopcorn.com Page 2... -
Page 3: Installation Instructions
Econo-Floss Model No. 3017, 3017SR, 3017SS, Floss-Maxx 3077, and 3077C INSTALLATION INSTRUCTIONS Inspection of Shipment After unpacking, check thoroughly for any damage which may have occurred in transit. Claims should be filed immediately with the transportation company. The warranty does not cover damage that occurs in transit, or damage caused by abuse, or consequential damage due to the operation of this machine, since it is beyond our control. -
Page 4: Electrical Requirements
Failure to wire properly will void the warranty and may result in damage to the machine. It is Gold Medal Products Company’s recommendation that this machine be plugged directly into a wall outlet. The use of extension cords is not recommended due to safety concerns, and may cause sacrificed and/or reduced performance. - Page 5 Econo-Floss Model No. 3017, 3017SR, 3017SS, Floss-Maxx 3077, and 3077C INSTALLATION OF FLOSS STABILIZER Place Floss Machine Pan on unit and install Whirl Grip Floss Stabilizer as shown below. 1) Place a Non-Metallic Whirl Clip over the rim of the Floss Pan. The out facing hooks go to the inside of the Floss Pan.
-
Page 6: Controls And Their Functions
Econo-Floss Model No. 3017, 3017SR, 3017SS, Floss-Maxx 3077, and 3077C OPERATING INSTRUCTIONS Controls and Their Functions MAIN SWITCH Turns motor “on” or “off” and supplies voltage to the heat switch. HEAT SWITCH Turns voltage to the heating element (ribbon) “on” or “off”. - Page 7 Econo-Floss Model No. 3017, 3017SR, 3017SS, Floss-Maxx 3077, and 3077C Sugar for Your Candy Ready to Use Flosssugar Our ready to use Flossugar is the preferred sugar for your new cotton candy machine; however 100% pure cane or beet sugar will do just fine. Our Flossugar gives you good rich colors, and great flavors, too.
- Page 8 Econo-Floss Model No. 3017, 3017SR, 3017SS, Floss-Maxx 3077, and 3077C HEAT CONTROL SETTINGS TEST Settings Test CAUTION Floss head operates at high speeds. Operator MUST keep hands and face clear of the floss head to avoid possible injury. Keep all spectators at a reasonable distance, and use a Floss Bubble for added customer protection.
- Page 9 Econo-Floss Model No. 3017, 3017SR, 3017SS, Floss-Maxx 3077, and 3077C MAKING FLOSS Pick a cone, if it sticks in the stack of cones, twist it off the stack. CAUTION Keep hands away from spinning head! Hold an inch or two of the pointed end of the cone between two fingers and a thumb. With a light flicking action, roll cone in the web of floss building up in the pan.
-
Page 10: Shutdown Procedure
Econo-Floss Model No. 3017, 3017SR, 3017SS, Floss-Maxx 3077, and 3077C FLOATER ADJUSTMENTS In operation, the floss will collect on the FLOSS STABILIZER. If the floss collects “low” on the stabilizer, twist the front (leading) edge of the leather floaters down. You get more lift and the floss will collect higher.
