- Page 1 Instruction Manual Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2017 Gold Medal Products Co. Part No. 69022...
-
Page 2: Safety Precautions
Read and understand operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862 022_060215 gmpopcorn.com... - Page 3 Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 SAFETY PRECAUTIONS (continued) WARNING DO NOT allow direct contact of this equipment by the public when used in food service locations. Only personnel trained and experienced in the equipment operation may operate this equipment. Carefully read all instructions before operation.
-
Page 4: Inspection Of Shipment
Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 INSTALLATION INSTRUCTIONS Inspection of Shipment After unpacking, check thoroughly for any damage which may have occurred in transit. Claims should be filed immediately with the transportation company. The warranty does not cover damage that occurs in transit, or damage caused by abuse, or consequential damage due to the operation of this machine, since it is beyond our control (reference warranty in back of manual). Manual Read and understand the operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1‐(800)‐543‐0862. Model Description 2388: Econo 8 oz. Popper. 2388‐00‐002: Econo 8 oz. Popper unit equipped with a PowerOff Control feature. Items Included with this Unit Aluminum Scoop 1 Cup Corn Measure Flavacol Measure 1/3 Cup Oil Measure (PN 2071) (PN 47147) (PN 47150) 6.5 cc (PN 47678) Instruction Manual Registration Black Crutch Tip... - Page 5 Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Setup This unit has been tested at the factory. 1. Remove all packaging and tape prior to operation. Remove accessories and carefully remove kettle packed in cabinet interior. 2. Place unit on a sturdy, level base. 3. Unit has 4 glide feet preinstalled at the factory (see image below). Install a Black Crutch Tip on each foot. Firmly push crutch tip over glide until it covers glide entirely. 4. Tilt kettle and insert into hanger arms, then allow kettle to return naturally to an upright position (see image below). 5. Plug kettle lead into receptacle located on ceiling of cabinet interior. Align keyed or hook shaped prong with the correct opening, then push plug all the way in and twist or rotate to lock in place. To unplug, untwist kettle plug before attempting to pull from receptacle. 6. Door knobs are shipped in accessories pack. Install a door knob with tee bolt on each popper door; install knob with screw on old maid pan. 7. After setup, unit should be cleaned prior to use (see Care and Cleaning section). Kettle lead shown plugged into kettle receptacle. Glide (pre‐installed at the factory) Black Crutch Tip Kettle shown mounted in hanger arms. General images shown for reference only.
-
Page 6: Electrical Requirements
3. The wall outlet must have the proper polarity. If in doubt, have a competent electrician inspect the outlet and correct if necessary. 4. DO NOT use a grounded to un‐grounded receptacle adapter (where applicable). 5. Install unit in a level position. CAUTION If the supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent or similarly qualified persons in order to avoid a hazard. 039_080614 gmpopcorn.com Page 6... -
Page 7: Controls And Their Functions
Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 OPERATING INSTRUCTIONS Controls and Their Functions KETTLE HEAT SWITCH Two position, ON/OFF lighted rocker switch ‐ supplies power to the heating element in the kettle. The green switch light ON indicates there is power to the kettle heating element. KETTLE MOTOR SWITCH Two position, ON/OFF lighted rocker switch ‐ supplies power to the kettle agitator motor. The Kettle Motor Switch MUST be ON at all times when there is popcorn (popped or un‐ popped) in the kettle. LIGHTS/WARMER SWITCH Two position, ON/OFF lighted rocker switch ‐ supplies power to the interior cabinet light and corn pan heat element. Label used on Models with PowerOff Control feature. Lights/Warmer Kettle Heat Switch Switch Kettle Motor Switch POWEROFF CONTROL (Model 2388‐00‐002 only) The PowerOff Control feature will automatically turn the kettle heat off after 15 minutes of idle time (no popcorn popped). The PowerOff Control will prevent the heat element and thermostat from cycling OFF‐ON if the Kettle Heat Switch is left on. This feature saves electrical power and extends the life of the kettle heating element and thermostat. When the Kettle Heat Switch is turned ON, and the kettle thermostat switches OFF, the PowerOff Control’s 15 minute timer starts; the 15 minute timer resets each time a batch of popcorn is popped. The small green neon light in the Kettle Heat Switch will blink OFF‐ON to indicate the kettle has been automatically turned OFF. -
Page 8: Popping Corn Instructions
Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Popping Corn Instructions This section describes instructions for popping Salted Popcorn. The popper is equipped with a corn, salt, and oil measure. We recommend flavored and colored coconut oil. Popcorn popped in coconut oil stays fresh longer and does not leave black deposits in the kettle like other oils. Use only top quality, fresh popcorn from reputable suppliers. Popping Salted (Standard) Popcorn Raw Popcorn Charge: Use corn measure provided (ex: for 6 oz. Kettle, use 6 oz. corn) Recommended Oil Volume: Oil volume is approx. 30% of corn amount (ex: for 6 oz. corn, use 2 oz. oil) Flavacol (Salt) Amount: Use small Flavacol scoop provided Premeasure all ingredients (adjust as needed for desired taste), or for best results use Mega‐Pop ® premeasured popcorn and oil pouch made for your kettle size. 1. Turn all switches ON. 2. To determine when kettle is ready to pop corn (about 4 minutes), test pop three kernels of corn in one ounce (30 ml) of popping oil. When kernels pop, kettle is ready. 3. Lift kettle lid, pour in popcorn and Flavacol, then add oil; close lid. 4. When corn has finished popping, gently dump the popcorn. Popping Tip: On final batch, turn Kettle Heat Switch OFF just as lids are forced open by the popping corn (kettle has plenty of heat to finish popping). This helps eliminate smoke/odor from any oil residue remaining in kettle. 5. -
Page 9: Care And Cleaning
Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Care and Cleaning DANGER Machine must be properly grounded to prevent electrical shock to personnel. DO NOT immerse in water. DO NOT clean appliance with a water jet. Always unplug the equipment before cleaning or servicing. 025_111616 WARNING To avoid serious burns, DO NOT touch the kettle while it is hot! - Page 10 Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Daily Unit Cleaning Instructions 1. With the machine OFF, unplug the unit and allow it to cool before attempting to clean. 2. Make sure to clean all pans/accessories in order to sanitize them before each use. 3. Take a clean, SLIGHTLY damp cloth and wipe excess grease from the glass and cabinet. 4. Wipe the stainless steel parts with a clean cloth and cleaner designed for stainless steel, such as Gold Medal Watchdog Stainless Cleaner (Item No. 2088). DO NOT use oven cleaners or abrasive materials as they will damage parts of the machine. 5. Clean the glass panels with glass cleaner. Gold Medal Watchdog Glass Cleaner (Item No. 2588) is recommended. Ammonia cleaners will damage the plastic doors. Use only non‐ammonia cleaners, such as Gold Medal Watchdog Glass Cleaner (Item No. 2588). gmpopcorn.com Page 10...
-
Page 11: Troubleshooting
Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Troubleshooting Issue Possible Cause Solution No Power to the Unit A. No Power to the Unit A. Make sure the unit’s power cord is plugged in. Kettle Does Not Heat A. Power to the Kettle A. Make sure kettle lead‐in cord is plugged in and twisted to lock into the kettle receptacle. B. Kettle Heat Switch B. Have a qualified service person check the voltage to and from the Kettle Heat Switch; if switch is defective, replace it. C. PowerOff Control C. Units with the PowerOff Control feature, kettle heat will automatically shut OFF after 15 minutes of idle time (no popcorn popped). The small green neon light in the Kettle Heat Switch will blink OFF‐ON to indicate the kettle has been automatically turned OFF. To restart kettle heating, cycle the Heat Switch OFF‐ON. Reference the Controls and Their Functions section of this manual. - Page 12 Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Agitator Set Collar Adjustment The following instructions describe how to properly adjust set collars on an agitator assembly with a floating stir rod. Agitator Assembly with a FLOATING Stir Rod Steps to Adjust Set Collars Gear Block Needle Bearing Step 1: Turn machine OFF, unplug unit, and (should set at least allow it to cool completely before attempting halfway into Gear Block) to adjust the agitator height. Step 2: Loosen the set screw in each set collar Agitator’s Spur Gear (should set halfway up on to be adjusted. Drive Motor Drive Motor Spur Gear) Spur Gear Step 3: With the kettle mounted in the popper, adjust the shaft so the Spur Gears are halfway engaged, and the Needle Bearing is at least halfway engaged in the gear block (reference image at right).
-
Page 13: Maintenance Instructions
Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 MAINTENANCE INSTRUCTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. DO NOT immerse any part of this equipment in water. DO NOT use excessive water when cleaning. -
Page 14: Ordering Spare Parts
Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 ORDERING SPARE PARTS 1. Identify the needed part by checking it against the photos, illustrations, and/or parts list. (General images may be used in manual for reference only.) 2. Use only approved replacement parts when servicing this unit. 3. When ordering, please include part number, part name, and quantity needed. 4. Please include your model number, serial number, and date of manufacture (located on the machine nameplate/data plate) with your order. 5. Address all parts orders to: Parts Department Gold Medal Products Co. 10700 Medallion Drive Cincinnati, Ohio 45241‐4807 Or, place orders by phone or online: Phone: (800) 543‐0862 (513) 769‐7676 Fax: (800) 542‐1496 (513) 769‐8500 E‐mail: info@gmpopcorn.com Web Page: gmpopcorn.com gmpopcorn.com Page 14... -
Page 15: Replacing Broken Glass
Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Replacing Broken Glass Broken glass panels can be easily replaced. Gold Medal Products Co. does not ship glass. It can be obtained from a local glass shop, always purchase tempered glass. GLASS DIMENSIONS (Height x Width x Thickness) Front Glass: 22 3/8” X 16 15/16” X 1/8” (1 Piece) Side Glass: 22 3/8” X 14 15/16” X 1/8” (2 Pieces) 1. Turn machine OFF, unplug unit and allow it to cool before attempting to replace glass. 2. Remove all loose pieces of glass (popper units: kettle may be removed to change glass). 3. Place a bungee (or large rubber band) around the unit to help hold the corner posts in place, then remove dome. 4. Remove all rigid glass channels from around glass to be replaced, set channels aside for reuse. Note: The rigid channels may be wedged in the corner posts or top and bottom glass extrusions, and must be removed before new glass can be installed. 5. Carefully remove the rest of the broken glass. 6. Apply decals (if desired) to new glass panel. 7. Slide rigid glass channels over exposed sides and bottom of new glass panel. 8. Lift motor plate just enough to allow the new glass panel to slide into the corner posts and down into the bottom glass extrusion. 9. Carefully lower the motor plate until the top glass extrusion secures glass in place. 10. - Page 16 Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 8 oz. Kettle Assembly (49472N) – Agitator Assembly View Overall Kettle 56000 Agitator Assembly 56000 **Apply Loctite 246 to bottom of set screws before installing. *See Parts List note. 16, 14 See Kettle Bottom Assembly. Complete Agitator Assembly (Includes Lids) Complete Kettle Assembly Part Number Item Part Description 49472N ACORN NUT 47702 8‐32 X 1/2 PHIL PAN M/S 47141 DUMP HANDLE RH 49314 DUMP HANDLE KNOB 47110 SPACER (For Dump Handle)
- Page 17 Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 8 oz. Kettle Assembly (49472N) – Kettle Bottom Assembly Kettle Bottom Assembly 49472N Element View 49472N Kettle Bottom Assembly 8, 9 Element View Thermostat Top Lock Nut ‐ Fastens thermostat. Install Lock Nut with triangle in UP position (as shown). ONE TIME USE ONLY, REPLACE NUT if removed. Lock Nut View Part Number Item Part Description 49472N 8 OZ. KETTLE BOTTOM ASSEMBLY (Complete 49489N Assembly ‐ includes parts listed below) KETTLE SHELL 49431 KETTLE LEAD ASSEMBLY 49328...
- Page 18 Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Cabinet Exterior – Front View 2085‐01‐000 Overall 8, 9 For Glass Panels, See Kettle see Replacing Assembly Glass section. Section 10, 11 General image shown for parts reference only. Part Number Item Part Description All Models FRONT GLASS DECAL 49158 8‐32” X 5/8” TYPE 23 HX HD 49052 TOP PAN 49452 GLASS EXTRUSION (Front Glass) 74164 GLASS EXTRUSION (Side glass) 49508 8‐32 x 5/16 SLOTTED HEX 49594 21 5/8” GLASS CHANNEL (used on sides of glass 49509...
- Page 19 Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Cabinet Exterior – Rear View 2085‐01‐000 Shown **Complete Door Hardware Kit (See next page for individual component breakdown). 2** 2** For Labels, see Safety Label Section. 5, 6 *CAUTION: If supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent, or similarly qualified persons in order to avoid a hazard. General image shown for parts reference only. Part Number Item Part Description All Models MAGNETIC CATCH 47561 2** COMPLETE DOOR HARDWARE KIT 61380 PLEXIGLASS DOOR 49395 DROP PANEL 49145...
- Page 20 Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Door Hardware Kit 61380 – Individual Component Breakdown Complete Door Hardware Kit (P/N 61380) (contains all parts shown above) Part Number Item Part Description 61380 KNOB LID LIFT 47120 TEE BOLT 75267 8‐32 X 5/16 SLOTTED HEX 49594 8‐32 X 3/8 PH PAN W/SEMS 42227 ACORN NUT #8‐32 47702 MALE HINGE SHORT LEFT 41349 FEMALE HINGE LEFT HAND 61359 FEMALE HINGE RIGHT HAND 61373 MALE HINGE SHORT RIGHT 41350 gmpopcorn.com Page 20...
- Page 21 Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Cabinet Interior – Hanger Assembly 2656 For Labels, see Safety Label Section. * See Parts List note. LED Light 9*, 10 Data Plate See Kettle Assembly section for Kettle parts breakdown. General image shown for parts reference only. Part Number Item Part Description All Models SMALL SWITCH BOX 48501 SWITCH BOX LABEL 48502 GREEN LIGHTED ROCKER SWITCH 42798 DPST ROCKER SWITCH 42532 LED REPLACEMENT NO PLATE 100544 POWER SUPPLY 24VDC 20W 55394 REAR HANGER ARM...
- Page 22 Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Cabinet Interior – Corn Pan/Element View 2085 Shown 3, 4 See Safety Label Section. General image shown for parts reference only. Part Number Item Part Description All Models WIRE DUCT 49091 (runs the entire length of the corner post) BOTTOM CORN PAN 49506 8‐32 X 3/8 SLT. HWH M/S 42044 8‐32 HEX M/S NUT 74149 CORNER COVER 49105 CORNER COVER – COVER 49104 STRIP HEAT ELEMENT 50W 49440 STRIP HEATER BRACKET 49425 gmpopcorn.com Page 22...
- Page 23 Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Dome Interior – Electrical Components 2656 LED Light PowerOff Control (Available on select models only.) General image shown for parts reference only. Part Number Item Part Description 2388 2388‐00‐002 LED REPLACEMENT NO PLATE 100544 100544 POWER SUPPLY 24VDC 20W 55394 55394 2A 20W POWER SUPPLY BRACKET 55414 55414 AUTO KETTLE POWEROFF CNTRL PCB 55402 BRACKET, KETTLE POWEROFF CNTRL 55427 6‐32 X 3/8 PHIL PAN M/S 39000 #6 INTERNAL TOOTH L/W 410SS 39001...
-
Page 24: Safety Labels
Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Safety Labels Kettle Lead‐In Label On units with PowerOff Control feature only. Power Cord Label Unit Labels Part Number Item Part Description 2388 2388‐00‐002 UNIVERSAL POPPER DECAL 41019 41019 LABEL UNPLUG TO CLEAN 76097 76097 MAIN GROUND LABEL 42375 42375 WARNING, SURFACE CONTACT 87087 87087 LABEL POWEROFF CNTRL 55436 CONDUIT WARNING LABEL 82840 82840 WARNING LABEL CORD 68720 68720 Accessories Item... -
Page 25: Wiring Diagram
Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Wiring Diagram Model No. 2388 gmpopcorn.com Page 25... - Page 26 Econo 8 Popcorn Machine Model No.: 2388, 2388-00-002 Model No. 2388-00-002 gmpopcorn.com Page 26...
-
