4.3.2 Adjustable Chart

Chart
• Click on
graph displays Temperature and Humidity and can be charted across the full span
(0-70ºC, and 0-100% RH) or within any narrow range (such as 20-30ºC). The time-base
can display one minute, one hour, one day, one week, one month or one year.
If a blank screen appears without any "java application running" or image of a
"Java logo", please verify you have the latest Java Runtime Environment
installed and configured according to the instructions (refer to Section 4.3.1).
If you do not have Java Runtime Environment, you may download it from our
website or contact the Customer Service Department nearest you.
temperature units: F or C
Actual Temperature
User selectable
temperature range
Number of degrees
per division
based on
temperature range
User selectable
temperature range
Start Time
User selectable time base
1 minute, 1 hour, 1 day,
1 week, 1 month, or 1 year
, the following page (Figure 4.8) should appear. The Java™ Applet
User selectable
Title
http://128.100.101.254
Alarm SP1(above)=044.5 F Alarm SP2(below)=033.5%RH
73.9
Temperature
122
9.0
F/Div
32
1 Day
02/20/2004 09:42:10
1 Minute
1 Hour
1 Day
1 Week
1 Month
1 Year

Figure 4.8 Adjustable Chart

Title
Flash Archive
Archives_Done
F
(1 Hours/Div)
Main Menu
17
Archives_Inactive:
1minute or 1hour
Archives_Enable:
1Day, 1Week, 1Month, or 1Year
Archives_Done:
displays after done archiving
your selected interval
044.2
Humidity
100%
0
%
02/21/2004 09:42:10
Actual Humidity
Humidity Ramp
from 0 to 100%
End Time
