12 | Keysight | PXI Vector Network Analyzer - Configuration Guide

For devices with Type-N connectors

Mechanical calibration kits
– 85054B Standard, DC to 18 GHz
Includes:
00909-60011 Type-N (m) fixed lowband load
00909-60012 Type-N (f) fixed lowband load
85054-60025 Type-N (m) short
85054-60026 Type-N (f) short
85054-60027 Type-N (m) open
85054-60028 Type-N (f) open
85054-60031 Type-N (f) to 7mm adapter
85054-60032 Type-N (m) to 7mm adapter
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
85054-80010 Type-N (f) sliding load
85054-80009 Type-N (m) sliding load
85054-60050 Type-N (f) connector gage
85054-60052 Type-N (f) gage master
85054-60051 Type-N (m) connector gage
85054-60053 Type-N (m) gage master
– 85054D Economy, DC to 18 GHz
Includes:
85054-60025 Type-N (m) short
85054-60026 Type-N (f) short
85054-60027 Type-N (m) open
85054-60028 Type-N (f) open
85054-60031 Type-N (f) to 7mm adapter
85054-60032 Type-N (m) to 7mm adapter
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
85054-60046 Type-N (m) fixed load
85054-60047 Type-N (f) fixed load
Electronic calibration kits
– N7550A economy ECal, DC to 4 GHz, 2-ports
– N7551A economy ECal, DC to 6.5 GHz, 2-ports
– N7552A economy ECal, DC to 9 GHz, 2-ports
– N7553A economy ECal, DC to 14 GHz, 2-ports
– N7554A economy ECal, DC to 18 GHz, 2-ports
– N755xA Series includes:
Option NMF with Type-N (m) to Type-N (f) ECal module
Option NMM with Type-N (m) to Type-N (m) ECal module
Option NFF with Type-N (f) to Type-N (f) ECal module
– N4431B Microwave ECal, 300 kHz to 13.5 GHz, 4-ports
Includes:
Option 020 module with:
N4431-60007 4 x Type-N (f) ECal module
N4431B-xxx mixed-connector options:
Connector Port A
Type Option
3.5 mm (f) 101
3.5 mm (m) 102
Type-N 50 ohm (f) 103
Type-N 50 ohm (m) 104
7-16 (f) 1 105
7-16 (m) 1 106
1. Limits ECal module high frequency to 7.5 GHz
– N4432A Microwave ECal, 300 kHz to 18 GHz, 4-ports
Includes:
Option 020 module with:
N4432-60003 4 x Type-N (f) ECal module
N4432A-xxx mixed-connector options:
Connector Port A
Type Option
3.5 mm (f) 101
3.5 mm (m) 102
Type-N 50 ohm (f) 103
Type-N 50 ohm (m) 104
– N4690B Microwave ECal, 300 kHz to 18 GHz, 2-ports
Includes:
Option M0F module with:
N4690-60004 Type-N (f) to Type-N (m) ECal module
Option 00M module with:
N4690-60005 Type-N (m) to Type-N (m) ECal module
Option 00F module with:
N4690-60006 Type-N (f) to Type-N (f) ECal module
Option 00A adds:
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
Port B Port C Port D
Option Option Option
201 301 401
202 302 402
203 303 403
204 304 404
205 305 405
206 306 406
Port B Port C Port D
Option Option Option
201 301 401
202 302 402
203 303 403
204 304 404
www.keysight.com/find/pxivna
