  • Page 1: Installation Instructions

    X10DR ® X10DR 2nd Generation Installation Instructions February 13th 2018 X10DR ® Commercial In Confidence...

  • Page 2: Before You Start

    ® For vehicles that isolate the vehicle battery after hours, it is recommended the X10DR be installed with a XPB-C14 power bank connected in series with the radio interface cable. The...
  • Page 3 XFPK Field Programming Kit. The pin is multiplexed so it can also be used to indicate gateway programmable function 5&6. A XSJB special junction box should be used to de-multiplex the function 5&6 status. X10DR ® Commercial In Confidence...
  • Page 4 I/O ports to be first programmed for such. On some radio devices a COR output is not available without modifying the host mobile. While this would be desirable, the X10DR features smart voice detect circuitry to adapt its operation in these cases where a radio COR is not available.
  • Page 5 PTT is grounded is normal. However, if a headset is NOT attached to the Hirose audio port, then grounding pin 8 by default causes the X10DR to transmit audio with substantially increased Mic sensitivity. The value of this Mic boost can programmed in the handset using the XFPK field programming kit.
  • Page 6 The X10DR is factory set to provide a nominal 80mVrms audio signal to the host radio’s mic input. This level can be adjusted via setting the Transmit Output Gain To Radio on the gateway to suit the particular radios requirement. The level should be adjusted (if necessary) to match the audio level &...

  • Page 7: Basic Installation

    Optional installation Accessories XEC-4.5 4.5 meter radio interface extension cable for installation requiring a long run between the mobile and the X10DR gateway. Cables may be daisy chained for longer runs. Mount on the vehicle roof or on a XIC-0.5...
  • Page 8 Handset 4.5 meter radio interface extension cable for installation requiring a long run between the mobile and the X10DR gateway. Cables may be daisy includes X10DRMC mobile charger & chained for longer runs. Qty 2 XIC-0.5 interface cable and XDIA dual interface (not used in this config).
  • Page 9 XEC-4.5 4.5 meter radio interface extension cable for installation requiring a long run between the mobile and the X10DR gateway. Cables may be daisy chained for longer runs. Mount on the vehicle roof or on a roof rack - clear of obstructions XIC-0.5...
  • Page 10 XJB-DCI Junction Box -Order separately XJB-DCI recommended for TDMA radio use. Plug X10DRMC into charger ports before using DC isolated X10DR ports. For non-TDMA radios order XJB. X10DRMC can plug into any port on XJB. XDCC 12V Auxiliary DC cable - Order separately...
  • Page 11 Multi X10DR Pro installation X10DR-PU2 X10DR-PU2 Mount on the vehicle roof or on a roof rack - clear of obstructions in the direction you wish to predominately communicate. XMPA “Sharkfin” multi-polarity antennas including 5.2 meters of low loss LMR200 type coax...
  • Page 12 XJB-DCI Junction Box -Order separately XJB-DCI recommended for TDMA radio use. Rear interface Plug X10DRMC into charger ports before using DC isolated X10DR ports. For non-TDMA radios order XJB. X10DRMC connector on your can plug into any port on XJB. mobile radio...
  • Page 13 XJB. XJB-DCI recommended for TDMA radio use. XIC-1.5 interface cable XDCC 12V Plug X10DRMC into charger ports before using DC isolated X10DR ports. (included in package) DC Aux. Cable For non-TDMA radios order XJB. X10DRMC Rear interface can plug into any port on XJB.
  • Page 14 -Order separately XDCC 12V Auxiliary DC cable - Order separately XDCC 12V Installations involving more than three X10DR gateways or X10DRMC mobile Rear interface DC Aux. Cable chargers should also order a XDCC 12V Auxiliary DC input cable which helps connector on your provide additional current when all devices are charging.
  • Page 15 DC Aux. Cable XDCC 12V Auxiliary DC cable - Order separately Rear interface Installations involving more than three X10DR gateways or X10DRMC mobile XIC-1.5 interface cable connector on your chargers should also order a XDCC 12V Auxiliary DC input cable which helps (included in package) provide additional current when all devices are charging.
  • Page 16 XPB Power Bank installation (Elite model shown) X10DR-EX2 X10DR-PU2 X10DR-PU2 XIC-1.5 interface cable (included in X10DR package) ® XPB-C14 Allows after hours XPB-C14 Power Bank charging for installations where the ® vehicle’s battery is isolated when the vehicle is not in use.
  • Page 17 1/18/16 2:45 PM This 6 way junction box provides connectivity between multiple X10DR devices. The device has a DC input port to allow ® connection of a XDCC 12VDC Aux. Cable to be connected when more than three X10DRMD gateway/X10DRMC mobile XJB Junction Box chargers are connected.
  • Page 18 XIC/XEC Series Interface Cables The X10DR gateway device connects to the mobile radio’s rear accessory port by way of a supplied 1.5m (5’) XIC interface cable and a separately ordered radio model specific XCA series adaptor. XCA adaptors are available for most popular mobile radios while adaptors for other models or for unique equipment interfaces can be supplied by custom order.
  • Page 19 A ground connection can easily be implemented during the installation process by soldering a wire (~22AWG) to the metal housing of the RJ45 connector that plugs into the X10DR Gateway, and then attaching the wire to a suitable chassis point near the Gateway. The ground strap should be soldered and secured to the cable via a small cable-tie as shown.
  • Page 20 UPS use The XPB can also be used to operate as a UPS (uninterrupted power supply) when the X10DR system is installed in a building with AC power rather than a vehicle. Connected as above between the X10DR gateway and the host communications device the XPB will continue to power the system in the event of loss of AC power.
  • Page 21 Where X10DR installations require use of multiple XMPA antennas, endeavour to keep the antennas ideally at least 1 meter (39”) apart for best performance.
  • Page 22 6 pin Hirose connector and your existing helmet wiring. CAUTION: To ensure maximum range when dismounted from the bike, the rider should attach the X10DR to their shoulder area and then make sure headset cable lengths do not interfere with the riders movements on the bike.
  • Page 23 X10DR Headset Cable Wiring XMCH-C Interface cable - Closed face - Electret Directional electret Suggested 4mm curly cable Mic Lo X10DR Programming: Mic Hi Set External Mic gain Std = 4 Spk Hi External Mic High Gain Boost = 6...
  • Page 24 X10DR Headset Cable Wiring WPSHC Interface cable - Heavy Duty - Electret Directional electret Suggested 4mm curly cable Mic Lo X10DR Programming: Mic Hi Set External Mic gain Std = 2 Spk Lo External Mic High Gain Boost = 6...
  • Page 25 Mic Hi Ground The WPNEX-X10 is designed to allow existing helmet head- sets that use the Nexus wiring convention to connect direct- Spk Lo ly to an X10DR handset device. Spk Hi Accessory Sense HR10-7S-6R Elite Programmable Pin 2 DC output.
  • Page 26 PTT not available: (includes XMC-SRM cable) XCA-SDM Suits Simoco SDM600 Plug 3.5mm plug into radio speaker XCA-XMC Converts XMC cables to 2nd Gen X10DR output. XMC-XCA Converts XIC cables for use with 1st Gen XCA-RJi Suits Icom basic radios...
  • Page 27 Solder (or change) desired wire(s), then apply hot-melt glue over the contact and wire to ensure joints remain secure in heavy vibration environments. Once everything is complete, push the connector back into the housing and ensure the four side clips are properly engaged. Procedure complete. X10DR ® Commercial In Confidence...
  • Page 28 Pin Outs Pin Outs the 0 ohm resistor from R641 to R640 changes pin 13 to the required analog Mic Hi input. TK690/ NX700 TK8150 TK590/ TK8180/ TK5710/ TK-690/790 etc Radio Control Unit PCB Black Color X10DR ® Commercial In Confidence...
  • Page 29 2/ No Emergency trigger on host mobile radio when Handset Emergency button is pressed but all other functionality correct. The XCA-RJ Buffered adaptor plugs into the X10DR gateway RJ45 port and then in series with the XIC interface cable and the specific radio XCA cable adaptor (either type 1 or 2).
  • Page 30 BLANK X10DR ® Commercial In Confidence...
  • Page 31 All rights reserved Wireless Corporation Limited ©2018 Wireless Pacific, X10DR, Liberate your mobile radio and their logos are trademarks or registered trademarks of Wireless Corporation Limited Revision O X10DR ® Commercial In Confidence...
