- Page 1 Secure Wireless Microphone ELITE CLASSIC Programming Feature Comparison WIRELESS PACIFIC ...WHEN IT MATTERS...
- Page 2 Exit Load File Press to exit program. Press to load a previously saved programming parameters Restart (important) to device from its saved PC location. Press to restart programmed device before removing programming cable WIRELESS PACIFIC ...WHEN IT MATTERS...
- Page 3 Handset Parameters ELITE CLASSIC WIRELESS PACIFIC ...WHEN IT MATTERS...
- Page 4 Default - ON Out of range turn off time Sets time in hours that a handset that is not actively connected to a WIRELESS PACIFIC gateway will remain powered on before turning itself off. Default - 8 hours ...WHEN IT MATTERS...
- Page 5 Limits all user monitored alert tones to level set below rather than being controlled by handset volume controls . Default OFF Alert Tone Volume Sets the value of the “Fixed Alert Tone” a user will hear from their handset. Default 5 WIRELESS PACIFIC ...WHEN IT MATTERS...
- Page 6 Causes an audible emergency warble tone to be transmitted over the host mobile Emergency repeat cycles radio channel. Default Off Sets the number of “Live Mic”, Tx and Rx cycles when Advanced Emergency is triggered. Default - 1 WIRELESS PACIFIC ...WHEN IT MATTERS...
- Page 7 Sets Hirose pin 2 to be either BAT+ (~3.8VDC) to power external accessories or bridged output speaker audio when pin 2 is set for speaker negative. Default - Speaker VE- Long Press Duration WIRELESS PACIFIC Sets time button must be pressed to detect a Long Press. Default - 1000mSec ...WHEN IT MATTERS...
-
Page 8: Gateway Parameters
Gateway Parameters ELITE CLASSIC WIRELESS PACIFIC ...WHEN IT MATTERS... - Page 9 When unchecked both Radio PTT and Talkaround audio is amplified for in-car monitor use. Default - OFF Radio Receive VOX/COR Enables VOX derived COR. Default - ON VOX Trigger Level Sets the gateway’s audio detect sensitivity for VOX derived COR. Default - 50 WIRELESS PACIFIC ...WHEN IT MATTERS...
- Page 10 Defines the length of time an input must be activated before the function is triggered or alternatively how long an output is activated when the assigned function has been triggered. A value of zero means an input triggers instantly. WIRELESS PACIFIC ...WHEN IT MATTERS...
