3.2. OUTPUTS

When selecting "Yes" in the Outputs parameter, the access to the outputs configuration will
appear in the menu on the left side. It looks as follows:
Figure 3.2. Outputs configuration
The outputs are grouped (in pairs) by channels, up to 3, named from A to C, disabled by default.
When selecting one of them, it is shown a drop-down box to configure the outputs as individual
outputs or shutter channels.
Figure 3.3. Possible configurations of the Channels
