2.2. SHUTTER CHANNELS

ACTinBOX MAX6 allows installing up to 3 different shutter drive control (or similar) on its
channels.
These channels allow controlling the shutter movements in a domotic installation.
Basic control: lower/raise the shutter
Precise control: precise controlling of the shutter and the slats (for blinds with slats)
Each channel (associated to a letter from A to C) consists of two consecutive individual outputs; i.e.,
Channel A includes the individual outputs 1 and 2; the channel B, 3 and 4 and the channel C, the
outputs 5 and 6. The first output of the channel sends the order to raise the shutter, whereas the
second one sends the order to lower the shutter. Therefore, the motor cables of the shutters, in
charge of carrying out these actions, should be properly connected to each output of the channel to
perform the required action.
The Table 1.1 shows the action carried out by the outputs of each channel:
Each channel can be configured as Shutter (No Slats) or as Blind (with Slats).
Besides the type of shutter, ACTinBOX MAX6 allows the configuration of the following
functionalities of the shutter channels:
Times. Allows configuring the main times associated to the movement of a shutter: time
up and time down, and also the definition of a security time to pause the movement when the
direction changes, and an additional time when the shutter gets its limit (top or bottom). For
blinds with slats, it is also possible to configure the secondary time, referred to the slats length
and the slats step time.
ZENNiO
AVANCE Y TECNOLOGÍA
Channel
Outputs
A
B
C
Table 1.1. Shutter channels: actions of the outputs
Action
1
Raise
2
Lower
3
Raise
4
Lower
5
Raise
6
Lower
vwww.zennio.com
6
