NEC PH3501QL User Manual page 146

3840 × 2160 (Aspect ratio: 16:9)
Screen
L2K-10F1
size
100" 82.7
120" 102.4
150" 126.0
200" 169.3
250" 212.6
300" 255.9
350" 299.2
400" 342.5
500" 433.1
600" 519.7
800" 692.9
1000" 866.1 1160.0–1610.2
Screen
size L2K-10F1
100" 2.1
120" 2.6
150" 3.2
200" 4.3
250" 5.4
300" 6.5
350" 7.6
400" 8.7
500" 11.0
600" 13.2
800" 17.6
1000" 22.0
TIP
• Calculation of the throw distance from the screen size
L2K-10F1 lens throw distance (m) = H × 0.99 : 82.7"/2.1 m (min.) to 866.1"/22.0 m (max.)
L4K-11ZM lens throw distance (m) = H × 1.33 to H × 1.84 : 111.5"/2.8 m (min.) to 1610.2"/40.9 m (max.)
L4K-15ZM lens throw distance (m) = H × 1.62 to H × 2.24 : 138.2"/3.5 m (min.) to 1960.6"/49.8 m (max.)
L4K-20ZM lens throw distance (m) = H × 2.11 to H × 3.57 : 192.9"/4.9 m (min.) to 3098.4"/78.7 m (max.)
L2K-30ZM lens throw distance (m) = H × 2.89 to H × 4.19 : 244.1"/6.2 m (min.) to 3661.4"/93.0 m (max.)
L2K-43ZM1 lens throw distance (m) = H × 4.17 to H × 5.88 : 354.3"/9.0 m (min.) to 5141.7"/130.6 m (max.)
L2K-55ZM1 lens throw distance (m) = H × 5.33 to H × 8.34 : 452.8"/11.5 m (min.) to 7291.3"/185.2 m (max.)
"H" (Horizontal) refers to the screen width.
* Figures differ by several % with the table above because the calculation is approximate.
Ex.: Throw distance when projecting on a 300" screen using the L4K-15ZM lens:
According to the "Tables of screen sizes and dimensions" in case of 3840 × 2160 (Aspect Ratio 16:9) (→ page 131), H (screen
width) = 261.5"/6.64 m.
The throw distance is 261.5"/6.64 m × 1.62 to 261.5"/6.64 m × 2.24 = 423.63"/10.76 m to 585.76"/14.87 m (because of the zoom
lens).
L4K-11ZM L4K-15ZM
111.5–157.5 138.2–192.9
134.9–189.0 166.6–232.3
169.8–240.2 209.2–291.3
228.0–318.9 280.3–389.8
286.3–401.6 351.3–488.2
344.6–480.3 422.3–586.6
402.8–559.1 493.3–685.0
461.1–641.7 564.4–783.5
577.5–803.1 706.4–976.4
694.1–964.6 848.4–1173.2
927.1–1287.4 1132.5–1566.9
1416.6–1960.6
L4K-11ZM L4K-15ZM
2.8–4.0 3.5–4.9
3.4–4.8 4.2–5.9
4.3–6.1 5.3–7.4
5.8–8.1 7.1–9.9
7.3–10.2 8.9–12.4
8.8–12.2 10.7–14.9
10.2–14.2 12.5–17.4
11.7–16.3 14.3–19.9
14.7–20.4 17.9–24.8
17.6–24.5 21.6–29.8
23.5–32.7 28.8–39.8
29.5–40.9 36.0–49.8
Lens model name
L4K-20ZM L2K-30ZM
192.9–318.9 244.1–354.3
228.3–381.9 295.3–429.1
283.5–472.4 370.1–539.4
374.0–629.9 500.0–720.5
464.6–783.5 626.0–905.5
555.1–937.0 752.0–1090.6
645.7–1090.6 881.9–1271.7
736.2–1248.0 1007.9–1456.7
921.3–1555.1 1259.8–1822.8
1102.4–1862.2 1515.7–2192.9
1464.6–2480.3 2023.6–2925.2
1830.7–3098.4 2531.5–3661.4
Lens model name
L4K-20ZM L2K-30ZM
4.9–8.1 6.2–9.0
5.8–9.7 7.5–10.9
7.2–12.0 9.4–13.7
9.5–16.0 12.7–18.3
11.8–19.9 15.9–23.0
14.1–23.8 19.1–27.7
16.4–27.7 22.4–32.3
18.7–31.7 25.6–37.0
23.4–39.5 32.0–46.3
28.0–47.3 38.5–55.7
37.2–63.0 51.4–74.3
46.5–78.7 64.3–93.0
129
8. Appendix
unit: inch
L2K-43ZM1 L2K-55ZM1
354.3–500.0 452.8–712.6
429.1–602.4 547.2–858.3
535.4–759.8 689.0–1078.7
720.5–1015.7 921.3–1444.9
901.6–1275.6 1153.5–1811.0
1086.6–1531.5 1385.8–2173.2
1267.7–1791.3 1622.0–2539.4
1452.8–2047.2 1854.3–2905.5
1818.9–2563.0 2322.8–3637.8
2185.0–3078.7 2787.4–4366.1
2917.3–4110.2 3724.4–5830.7
3645.7–5141.7 4657.5–7291.3
L2K-43ZM1 L2K-55ZM1
9.0–12.7 11.5–18.1
10.9–15.3 13.9–21.8
13.6–19.3 17.5–27.4
18.3–25.8 23.4–36.7
22.9–32.4 29.3–46.0
27.6–38.9 35.2–55.2
32.2–45.5 41.2–64.5
36.9–52.0 47.1–73.8
46.2–65.1 59.0–92.4
55.5–78.2 70.8–110.9
74.1–104.4 94.6–148.1
92.6–130.6 118.3–185.2
unit: m
