Tightening Torque - Suzuki FD 110 XCS Service Manual

TIGHTENING TORQUE

ENGINE
ITEM
Cylinder head nut
Cylinder head bolt
Cam sprocket bolt
Cam chain tensioner bolt
Starter clutch bolt
Spark plug
Valve clearance inspection cap bolt
Cylinder head right cover bolt
Cylinder head left cover bolt
Cam chain guide bolt
First clutch nut
Second clutch nu
Shift arm stopper bolt
Magneto rotor nut
Engine oil drain plug
Exhaust pipe bolt
Muffler mounting bolt
Engine mounting bolt
Oil filter cap bolts
Sprocket nut
SERVICING INFORMATION
N-m
18.0-22.0
8.0-12.0
9.0-11.0
8.0-12.0
14.0-16.0
10.0-12.0
10
8.0-12.0
8.0-12.0
8.0-12.0
40.0-60.0
40.0-60.0
19
70.0-90.0
15.0-20.0
8.0-12.0
26
55
8.0-12.0
23
7-23
Kg-m
1.8-2.2
0.8-1.2
0.9-1.1
0.8-1.2
1.4-1.6
1.0-1.2
1.0
0.8-1.2
0.8-1.2
0.8-1.2
4.0-6.0
4.0-6.0
1.9
7.0-9.0
1.5-2.0
0.8-1.2
2.6
5.5
0.8-1.2
2.3
