Sip Replacement Parts - Frick QUANTUM LX Installation Operation & Maintenance

Frick SAP
Number Number
639A0185H10 483963
639A0185H30 483966
639A0185H31 483967
639A0206H05 484047
639D0199H01 703164
649D6101G01 1032704 Touchscreen glass w/overlay of Frick logo
639A0290G07 1073320 Quantum™ SIP Program Flash Card (Version 2.00)
639B0116H01 677556
639D0236H01 105758
639B0118H01 670744
639B0126H01 884854
639D0191H03 696516
333Q0001786 N/A
639B0115H02 642308
649C1158G01 1034948 Q5 (Advantech Q5) (Does not include interconnect harness kit)
639B0116H01 677556
QUANTUM™ LX/HD SYSTEM INTERFACE PANEL
INSTALLATION-OPERATION-MAINTENANCE

SIP REPLACEMENT PARTS

Control Power
2-Pos. Selector Switch (Control Power)
Latch, 3 Across (Attaches contact block to switch mechanism)
Normally Open Contact Block (for Control Power Switch)
Circuit Breaker, 5 Amp.
Display Accessories
15" Color Display (Indoor)
Flash Cards and Software
Harnesses
DC power-I/O Comms harness
SIP Harness, Ground
Display Harness
LED Inverter Harness
Harness Kit, Q5 to Interface Board Interconnect
Miscellaneous
Battery, 3V (located on Q5 board)
Power Supply
DC power supply – 12 VDC
Q5 Boards
Interface Board (Does not include interconnect harness kit)
Description
090.030-IOM (OCT 13)
Page 21
