DVC6000 Digital Valve Controllers

Parts Ordering

Whenever corresponding with your Emerson Process
Management sales office about this equipment,
always mention the controller serial number. When
ordering replacement parts, refer to the 11−character
part number of each required part as found in the
following parts list. Parts which do not show part
numbers are not orderable.
Use only genuine Fisher replacement
parts. Components that are not
supplied by Emerson Process
Management should not, under any
circumstances, be used in any Fisher
instrument. Use of components not
supplied by Emerson Process
Management may void your warranty,
might adversely affect the
performance of the instrument, and
could cause personal injury and
property damage.
8
Note
All part numbers are for both
aluminum and stainless steel
constructions, unless otherwise
indicated.

Parts Kits

Kit Description
1* Elastomer Spare Parts Kit (kit contains parts to
service one digital valve controller)
Standard
Extreme Temperature option
(fluorosilicone elastomers)
2* Small Hardware Spare Parts Kit (kit contains parts
to service one digital valve controller)
3 Conversion Kit (To convert a DVC6010 to DVC6020 or
a DVC6015 to DVC6025)
Also see note below
When converting a DVC6010 to a DVC6020 for
pipe−away construction, also order pipe−away bracket
kit, item 7.
8-2
WARNING
Part Number
19B5402X012
19B5402X022
19B5403X012
19B5405X012
Note
Key Description
4 Conversion Kit (to convert a DVC6020 to DVC6010 or
a DVC6025 to DVC6015)
5 Feedback Arm Kit (contains feedback arm assembly, qty. 5,
to convert a 2052 size 2 and 3 DVC6020 to a
2051 size 1 DVC6020)
6 Alignment Pin Kit
[kit contains 15 alignment pins (key 46)]
7 Pipe-Away Bracket Kit (DVC6020) [kit contains
mounting bracket (key 74) and O−ring (key 75)]
Standard
Extreme Temperature option
(fluorosilicone elastomers)
8* Seal Screen Kit
[kit contains 25 seal screens (key 231)
and 25 O−rings (key 39)]
Standard and Extreme Temperature option
(fluorosilicone elastomers)
9 Terminal Box Kit, aluminum
Standard
Standard, Natural Gas approved
Extreme Temperature option (fluorosilicone
elastomers)
Extreme Temperature option (fluorosilicone
elastomers) Natural Gas Approved
Stainless Steel, Natural Gas Approved
Stainless Steel, Extreme Temperature option
(fluorosilicone elastomers), Natural Gas
approved
10* I/P Converter Kit
Standard
For Extreme Temperature option
(fluorosilicone elastomers)
11 Adjustment Arm Kit
(includes washer, nut and adjustment arm)
12* PTFE Sleeve Kit
[For pot bushing assembly (kit includes 10 sleeves and
Lubricant)]
DVC6010 and DVC6020
DVC6030
13* Spare Module Base Assembly Kit
[kit contains module base (key 2); drive screws, qty. 2,
(key 11); shield/label (key 19); hex socket cap screw, qty. 3,
(key 38); self tapping screw, qty. 2 (key 49); pipe plug, qty. 3
(key 61); retaining ring, qty. 3 (key 154); screen (key 236);
and flame arrestors, qty. 3 (key 243)]
Aluminum
Stainless Steel
*Recommended spare
Part Number
14B5072X112
GE44419X012
14B5072X092
19B5404X012
19B5404X022
14B5072X182
19B5401X012
19B5401X072
19B5401X022
19B5401X082
19B5401X092
19B5401X112
38B6041X152
38B6041X132
14B5072X132
GE08726X012
GE08727X012
GE18654X012
GE18654X022
September 2013
