WM5-50
5-Stage Reverse Osmosis System
System tested and certi fi ed by NSF Internati onal
System tested and certi fi ed by NSF Internati onal
against NSF/ANSI Standard 58 for the reducti on of
against NSF/ANSI Standard 58 for the reducti on of
substances specifi ed on the performance data sheet.
substances specifi ed on the performance data sheet.
41840 McAlby Court, Suite A
Murrieta, CA 92562
800-451-9343, FAX 951-894-2801
www.nimbuswater.com
41840-A McAlby Court, Murrieta, CA 92562
(800) 451-9343 · www.nimbuswater.com
1
Rev: 07/12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WaterMaker Five WM5-50 and is the answer not in the manual?

Questions and answers

Related Manuals for Nimbus Water Systems WaterMaker Five WM5-50

Summary of Contents for Nimbus Water Systems WaterMaker Five WM5-50

  • Page 1 WM5-50 5-Stage Reverse Osmosis System System tested and certi fi ed by NSF Internati onal System tested and certi fi ed by NSF Internati onal against NSF/ANSI Standard 58 for the reducti on of against NSF/ANSI Standard 58 for the reducti on of substances specifi...
  • Page 2 Please fi ll out the following informati on at the ti me of installati on. Save for future reference. WaterMaker Five WM5-50 Model: Date Code: Install Date: Sold by: Installed By: Service Center Phone Number:...
  • Page 3 Introducti on to the WaterMaker Five Congratulati ons on your purchase of the WaterMaker Five reverse osmosis system. The WaterMaker Five features a four-stage prefi lter, membrane and postf ilter housed in a single cartridge. The fi ft h stage, an in-line carbon fi lter, is placed between tank and faucet.

  • Page 4: Limited Warranty

    Limited Warranty This Limited Warranty extends to the original purchaser of the system only. This warranty covers all Manufacturer-supplied items only that prove to be defecti ve in material, workmanship or factory preparati on. This warranty covers parts only; all labor is excluded from this war- ranty, including, but not limited to, services related to the removal, replacement, installati on, adjustment, maintenance and/or repair of the unit or its components items.

  • Page 5: Performance Data Sheet

    Performance Data Sheet System Performance This system has been tested according to NSF/ANSI 58 for reducti on of the substances listed below. The concentrati on of the indicated substances in water leaving the system was reduced to a concentrati on less than or equal to the permissible limit for water leaving the system, as specifi...

  • Page 6: Arsenic Fact Sheet

    Arsenic Fact Sheet Arsenic (AS) is a natually occuring contaminant found in many ground waters. Arsenic in water has no color, taste or odor. It must be measured by a lab test. Public water uti liti es must have their water tested for arsenic. You can get the results from your water uti lity.
  • Page 7 41840-A McAlby Court, Murrieta, CA 92562 (800) 451-9343 · www.nimbuswater.com...

  • Page 8: System Specifications

    System Specifi cati ons Dimensions and Weight System - 9.75” W x 13.5” D x 15.5” H ( 24.8 x 34.3 x 39.4 cm), 11 lbs. (5 kg.) Shipping Box - 14.5"L x 11.25"W x 20"H (36.8 x 28.6 x 50.8 cm), 13.7 lbs. (6.2 kg.) A.
  • Page 9 Push Handle Airgap Faucet Note: This faucet requires a 1¼" opening in the sink or countertop. 1. Locate the faucet parts bag and arrange the parts on the countertop in the sequence shown. 2. The last part in the sequence, the quick connect adapter (6), Installati on Videos will be found in the smaller parts bag.
  • Page 10 Feed and Drain Connecti on Feed Connecti on 1. Locate and turn off the angle stop valve on the cold water line feeding the sink. This valve will usually be located under the sink on the pipe coming out of the wall. 2.
  • Page 11 System Acti vati on and Flushing System Acti vati on and Inspecti on 1. Check all tubing connecti ons to ensure they are fi rmly seated. CHECK TO SEE THAT THE CARTRIDGE RETAINER CLIP IS PROPERLY ENGAGED AND LOCKED. Failure to keep the retaining clip in place will result in accidental leaks and fl ooding. 2.

  • Page 12: Installation Checklist

    Installati on Checklist 1. System is located where it will not be subject to physical impacts or rough contact by heavy objects. 2. Feed water pressure to the unit is no less than 40 psi and no greater than 80 PSI. 3.

  • Page 13: Maintenance

    Maintenance Cartridge Replacement Close the feed water shut-off valve. Close the tank shut-off valve. Open the dispensing faucet to relieve system pressure. Close dispensing faucet when fl ow has stopped. Remove the cover from the front of the system. Remove the retaining clip. Pull the cartridge off the system evenly at top and bott om.
