Compact Par 7/15 Q4

Description of the device

Features
The Compact Par 7/15 Q4 is a compact parcan with high output and great effects.
● Double bracket
● Input voltage: 100-240V AC, 50/60Hz
● Drive Current: 350mA/color
● Refresh rate: 1,2 kHz
● Power consumption: 95W
● DMX channels: 4, 6 or 10 channels
● OLED display for easy setup
● Light source: 7 x 15W RGBW LEDs
● Output @2m: 8950lux
● Control modes: Auto, Sound-controlled, Static color, Master/Slave, DMX
● Control protocol: DMX-512
● Dimmer: 0-100%
● Strobe: 0,5-10Hz
● Beam Angle: 15°
● Protection rate: IP-20
● Housing: Die-cast black powder coated aluminum
● Cooling: Convection
● Connections: ProPower connectors (IN/OUT), 3-pin XLR (IN/OUT), 5-pin XLR (IN/OUT)
● Fuse: F2AL/250V
● Dimensions: 260 x 105 x 300 mm incl. bracket (LxWxH)
● Weight: 3,8 kg

Front

01) Double mounting bracket
02) 7 x 15W RGBW LEDs
03) Adjustment screw
Ordercode: 42599
7
Fig. 01
