- Page 1 MANUAL ENGLISH Parcan 64 Floorspot Ordercode: 30420/30421 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Parcan 64 Floorspot Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Connection with the mains ............................5 Return Procedure ................................6 Claims ....................................6 Description of the device ..............................7 Optional accessories ..............................7 Overview .................................. -
Page 3: Warning
Your shipment includes: ● Showtec Parcan 64 Floorspot with 0,8m Schuko power cable ● 1x Filter frame ● User manual... - Page 4 If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 5: Operating Determinations
Parcan 64 Floorspot Operating Determinations ● This device is not designed for permanent operation. Regular operation breaks will ensure that the device will serve you for a long time without defects. ● The minimum distance between light-output and the illuminated surface must be bigger than 0,5 meter. -
Page 6: Connection With The Mains
Parcan 64 Floorspot The Parcan 64 Floorspot can be placed on a flat stage floor or mounted to any kind of truss by a clamp. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power plug. Always check if the right color cable is connected to the right place. -
Page 7: Return Procedure
Parcan 64 Floorspot Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture. -
Page 8: Description Of The Device
Parcan 64 Floorspot Description of the device Features The Showtec Parcan 64 Floorspot is a parcan with high output and great effects. • Lamp: PAR 64 • Lamp socket: GX16D (max 230V) • Capacity: max 1000W • Input voltage: 230V, 50Hz •... -
Page 9: Lamp Housing
Damages caused by non-observance are not subject to warranty. Installing the Lamp The Showtec Parcan 64 Floorspot uses the GX16d (ordercode 80107) as manufactured by all popular manufacturers. Use only the appropriate lamp for your unit. Note that, product versions that use other lamps, may be offered in the future. Check your product specification label for information. - Page 10 Parcan 64 Floorspot Procedure: 01) Disconnect the Parcan 64 Floorspot from power before installing the lamp. 02) Pull the spring lever in the direction of the arrow and remove the rear cover of the lamp (Fig. 03). 03) Remove the fixation ring by pressing it together (Fig. 04). 04) Remove the lamp from the box and hold it by the base.
-
Page 11: Set Up And Operation
Parcan 64 Floorspot Set Up and Operation Follow the directions below, as they pertain to your preferred operation mode. Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. Always disconnect from electric mains power supply before cleaning or servicing. -
Page 12: Changing The Lamp
04) If you are unable to determine the cause of the problem, do not modify the Parcan 64 Floorspot, as this may damage the unit and the warranty will become void. 05) Return the device to your Showtec dealer. Problem... -
Page 13: Product Specifications
Parcan 64 Floorspot Product Specifications Model: Showtec Parcan 64 Floorspot Input voltage: 230V, 50Hz Capacity: max 1000W Lamp socket: GX16D (max 230V) Housing: Die-cast aluminum Cooling: Convection IP rating: IP20 Power cable 0,8m with Schuko connector Filter frame: Included Dimensions:... -
Page 14: Dimensions
Parcan 64 Floorspot Dimensions Ordercode: 30420/30421... -
Page 15: Notes
Parcan 64 Floorspot Notes Ordercode: 30420/30421... - Page 16 ©2017 Showtec...
