Figure 4.1: Typical DSView 3 Software System Firewall Configuration
Table 4.4: Typical DSView 3 Software System Firewall Configuration Descriptions
Number Description
1 DSView 3 Software Client
2 HTTPS
3 Proxy
4 Firewall

VPNs

A Virtual Private Network (VPN) is a secure network that uses public infrastructure and typically
includes several Wide Area Network (WAN) components that may impact performance of the
VPN.
Typically, two sites are connected in a VPN network using WANs and a router. This setup provides
a secure network between the two sites, but processing is slow.
Several factors related to the network setup, including the DSView 3 software database replication
schedule and methods of device access, can affect the speed of a multi-site VPN network. The
trade-off must be made based on the network setup.
Chapter 4: Basic Operations
Number Description
5 DSView 3 Server
6 Proxy
7 KVM Switch or Serial Console Appliance
8 Target Devices
51
