DSView 3 Software Client
HTTP
Port 80
Figure B.5: Generic Appliance Session Ports
If Active Directory or LDAP external authentication is being used within your DSView 3 software
system, TCP/IP ports 389 and 636 are used for connections between the DSView 3 server and the
external authentication server. Port 389 is typically used for non-SSL connections and port 636 is
used for SSL connections. You may configure the ports used by an Active Directory or LDAP
external authentication server using the Authentication Service Connection Settings window. See
Authentication Services on page 60.
TCP/IP
HTTPS
TCP/IP
Port 23
Generic Appliance
Appendices
DSView 3 Server
361
