370 DSView 3 Software Installer/User Guide
• EID - The Electronic ID (EID) number of the IQ module attached to the server.
Table C.3: DSR Remote Operations Content Area Icons (Servers View)
Icon
Power view
Selecting Power in the side navigation bar of the DSR Remote Operations window will display a
list of power device sockets attached to the switch and their status.
Table C.4: DSR Remote Operations Content Area Icons (Power View)
Icon

Version view

Selecting Version in the side navigation bar of the DSR Remote Operations window will display
version information for the following items:
• Application
Description
A target device that is powered up and has no established KVM Video Viewer sessions
A target device that has an active KVM Video Viewer session
A target device that is not powered up
A target device that is powered up but cannot establish a KVM connection because the path
to the target device is blocked (for example, a cascade switch has only one user port and that
port is already connected to another target device)
Description
The power device socket is powered up
The power device socket is powered down
The power device socket is cycling
The socket is unlocked (supported only on certain power device types)
The socket is locked (supported only on certain power device types)
