FIG.A
FIG.B
FIG.C
IFC17019.01
www.powercommander.com
2008-2011 Kawasaki Brute Force 750
Use the following instructions for 2008-2011 models.
1
Remove the seat.
2
Remove the right hand side cover as shown in Figure A.
3
Locate the black 6-pin connector that comes from the throttle bodies.
This connector is located on the right hand side of the Quad near the upper
frame rail.
4
Unplug this connector as shown in Figure B.
5
Attach the connectors from the PCFC harness to the stock wiring harness and
throttle body harness as shown in Figure C.
2008-2014 Kawasaki Brute Force 750 - 3
