Package Contents

Before you start the installation of the switch, please check the package contents.
— PT-C-VGAHD
— Power supply unit (+5VDC, 2A)
— User's Guide
1.4

Before Installation

 Put the product in an even and stable location. If the product falls down or drops, it may cause an
injury or malfunction.
 Don't place the product in too high temperature (over 50°C), too low temperature (under 0°C) or
high humidity.
 Use the DC power supply unit with correct specifications. If inappropriate power supply is used then
it may cause a fire.
 Do not twist or pull by force ends of the cable. It can cause malfunction.
1.5

Panel Descriptions

FRONT PANEL — PT-C-VGAHD
1. SPDIF In: Digital S/PDIF input
2. STEREO IN: Connect to an analog audio source
3. VGA IN: VGA input from a video source
x1
x1
x1
