Manual
SC-SD2
HD-SDI/SDI to HDMI/DVI Video Converter
User's Manual
9A Bergen Tpke Little Ferry, NJ 07643 USA
Tel: +1.201.488.3232
Fax: +1.201.621.6118
E-mail: support@dtrovision.com
www.dtrovision.com
For order support, please contact your local dealer.
For technical support, please contact us at support@dtrovision.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PureLink SC-SD2
Summary of Contents for PureLink SC-SD2
- Page 1 SC-SD2 HD-SDI/SDI to HDMI/DVI Video Converter User’s Manual 9A Bergen Tpke Little Ferry, NJ 07643 USA Tel: +1.201.488.3232 Fax: +1.201.621.6118 E-mail: support@dtrovision.com www.dtrovision.com For order support, please contact your local dealer. For technical support, please contact us at support@dtrovision.com...
-
Page 2: Table Of Contents
Unpacking Each DTROVISION HD/SDI converter package includes the following items; DTROVISION HD/SDI (SC-SD2) Unit One (1) 5V, 3A Power Supply Adapter User manual CONTENTS Contents Description, General Specification Environmental and Reliability Specifications Supported I/O Resolutions Panel Descriptions Mechanical Specification Technical Specification... -
Page 3: Description, General Specification
Description General Specification : DTROVISION SC-SD2 ITEM DESCRIPTION Model Name SC-SD2 Input Signal HD-SDI Output Signal DVI/HDMI VIDEO YCbCr(422) Input format VIDEO RGB(444), YCbCr(444), YCbCr(422) Output format Input format I2S / 48Khz AUDIO Receptacle DC Power Jack for +5V power in the rear panel... -
Page 4: Supported I/O Resolutions
Supported I/O Resolutions VIDEO INPUT Input - Data Format SMPTE format YCbCr(4:2:2) Input - Connector SDI BNC SMPTE-424M 1080p (60/59.94) SMPTE-274M 1080i (60/59.94/50) Input Signal Resolution SMPTE-296M 1080p (25/24/23.976) SMPTE-260M 720p(60/59.94/50) SMPTE-259M 480i (59.94), 576i(50) VIDEO OUTPUT DVI/HDMI format Output – Data Format RGB(444), YCbCr(444), YCbCr(422) Output –onnector DVI-I / HDMI female connector... -
Page 5: Panel Descriptions
Panel Descriptions < Front-Video Input> Power switch Power indicator light Firmware update PS2 port (Programmer use only) HD-SDI Inputs < Rear-Video Output> Status indicator LED 1) Video sync detection LED 2) DVI output connection status LED 3) HDMI output connection status LED HDMI output port DVI output port 5V power jack... -
Page 6: Mechanical Specification
Mechanical Specification [Dimensions] SC-SD2: 117 x 105 x 33 (mm) [Connector] DVI Connector: DVI-I 29-pin female (Digital only) HDMI Connector: HDMI female HDSDI/SDI Connector: BNC female Firmware Download Port: PS2 female [Power]. Power: +5V DC Toggle switch ON/OFF [LED Indicators] Power: Power On... -
Page 7: Technical Specification
Technical Specification [Data rates and Maximum resolution] Data rates and Resolution Input Video Bandwidth 2.97Gbps Output Video Bandwidth 2.97Gbps Maximum Input Resolution 1920x1080p/60Hz Maximum Output Resolution 1920x1080p/60Hz ※ The HDMI output is prior to DVI output when HDMI and DVI port is concurrently connected to Monitor or TV. 1-7 Technical Specification... -
Page 8: Warranty Information
Warranty Information 1 (One) Year Warranty DTROVISION warrants SC-SD2 HD/SDI converter to be free from defects in workmanship and materials, under normal use and service, for a period of one (1) year from the date of purchase from DTROVISION or its authorized resellers. -
Page 9: Troubleshooting
Troubleshooting Problem Remedy Actions Make sure the 5V power is plugged in the Converter not back of the unit. Operate Check to see if the power LED light is on. 1. If you are using copper based HDMI cable, overall length of the cables (length of the cable from video source to switch and length of the cable from switch to display) should not exceed 20ft.
