PureLink SC-DS1 User Manual

3g hdmi/dvi to hd-sdi/sdi video converter
Hide thumbs Also See for SC-DS1:

Advertisement

SC-DS1
3G HDMI/DVI to HD-SDI/SDI Video Converter
TM
PureLink
535 East Crescent Avenue
Ramsey, NJ 07446
USA
Tel: +1.201.488.3232
Fax: +1.201.621.6118
E-mail:
sales@purelinkav.com
www.purelinkav.com
For order support, please contact your local dealer.
For technical support, please contact us at
support@purelinkav.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC-DS1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PureLink SC-DS1

  • Page 1 SC-DS1 3G HDMI/DVI to HD-SDI/SDI Video Converter PureLink 535 East Crescent Avenue Ramsey, NJ 07446 Tel: +1.201.488.3232 Fax: +1.201.621.6118 E-mail: sales@purelinkav.com www.purelinkav.com For order support, please contact your local dealer. For technical support, please contact us at support@purelinkav.com...
  • Page 2: Table Of Contents

    PureLink by Dtrovision Table of Contents 1-1 Package Contents 1-2 Description, General Specification 1-3 Environmental and Reliability Specifications 1-4 Supported I/O Resolutions 1-5 Panel Descriptions 1-6 Mechanical Specification 1-7 Technical Specification 1-8 Warranty Information p.10...
  • Page 3: Package Contents

    PureLink by Dtrovision 1-1 Package Contents Please make sure all of the following items are included in the package: 1) SC-DS1 Unit 2) DC 5V 3A Power supply adapter 3) User manual...
  • Page 4: Description, General Specification

    PureLink by Dtrovision 1-2 Description, General Specification Description Item SC-DS1 Model Input Signal DVI/HDMI Output Signal HD-SDI VIDEO RGB(444), YCbCr(444), YCbCr(422) Input format VIDEO YCbCr(422) Output format Input format I2S / 48Khz AUDIO DC Power Jack for +5V power in the rear panel...
  • Page 5: Environmental And Reliability Specifications

    PureLink by Dtrovision 1-3 Environmental and Reliability Specifications [Recommended Operating Conditions] Parameter Symbol Min. Typ. Max. Units Operating Temp. Storage Temp. °C Storage Humidity...
  • Page 6: Supported I/O Resolutions

    PureLink by Dtrovision 1-4 Supported I/O Resolutions VIDEO INPUT Input – Data DVI/HDMI format Format. RGB(444), YCbCr(444), YCbCr(422) Input – Connector DVI-I / HDMI female connector 1080p(60/59.94), 1080i(60/59.94,50), Input - Resolution 1080p(25/24/23.976) 720p(60/59.94/50), 480i(59.94), VIDEO OUTPUT Output - Data SMPTE format YCbCr(4:2:2)
  • Page 7: Panel Descriptions

    PureLink by Dtrovision 1-5 Panel Descriptions < Front-Video Input > - Status indicator LED 1) Video sync detection LED 2) DVI input connection status LED 3) HDMI input connection status LED - HDMI Input port - DVI Input port - 5V power jack <...
  • Page 8: Mechanical Specification

    PureLink by Dtrovision 1-6 Mechanical Specification [Dimensions] - SC-DS1: 117 x 105 x 33 (mm) [Connector] - DVI Connector: DVI-I 29-pin female (Digital only) - HDMI Connector: HDMI female - HDSDI/SDI Connector: BNC female - Firmware Download Port: PS2 female [Power].
  • Page 9: Technical Specification

    PureLink by Dtrovision 1-7 Technical Specification [Data rates and Maximum resolution] Data rates and Resolution Input Video Bandwidth 2.97Gbps Output Video Bandwidth 2.97Gbps Maximum Input Resolution 1920x1080p/60Hz Maximum Output Resolution 1920x1080p/60Hz ※ The HDMI input is prior to DVI input when HDMI and DVI port is concurrently connected to video...
  • Page 10 PureLink shall not be liable for any damages whatsoever caused by Product or the failure of Product to perform, including incidental or consequential damages. PureLink shall not be liable for any claim made by a third party or made by the purchaser for a third party.
