Section 2: Specifications

Item
Units
HDMI compliance
DVI compliance
Video bandwidth
Video support
Audio support
Input TMDS signal
Input DDC signal
PCB stack-up
Input
Output
HDMI connector
VGA connector
RCA connector
3.5mm connector
Control Switch
Environmental
Operating Temperature
Storage Temperature
Relative Humidity
Single-link 165MHz [4.95Gbps]
Up to single link: 1080p@60, WUXGA [1920x1200@60Hz], UXGA
1.2 Volts [peak-to-peak]
5 Volts [peak-to-peak, TTL]
4-layer board [impedance control — differential 100Ω; single 50Ω]
Type A [19-pin female]
HD-15 [15-pin D-sub female]
Coaxial S/PDIF digital audio [PCM 48kHz]
20~90% RH (no condensation)
www.purelink.de
Description
PT-C-VGAHD
HDMI
N/A
Stereo audio
1x VGA
1x RCA
1x 3.5mm
1x HDMI
Analog stereo audio
2-pin DIP switch
0~40°C [32~104°F]
-20~60°C [-4~140°F]
