SC-SD2
HD-SDI/SDI to HDMI/DVI Video Converter
TM
PureLink
535 East Crescent Avenue
Ramsey, NJ 07446
USA
Tel: +1.201.488.3232
Fax: +1.201.621.6118
E-mail:
sales@purelinkav.com
www.purelinkav.com
For order support, please contact your local dealer.
For technical support, please contact us at
support@purelinkav.com
Advertisement
Table of Contents
Related Manuals for PureLink SC-SD2
Summary of Contents for PureLink SC-SD2
- Page 1 SC-SD2 HD-SDI/SDI to HDMI/DVI Video Converter PureLink 535 East Crescent Avenue Ramsey, NJ 07446 Tel: +1.201.488.3232 Fax: +1.201.621.6118 E-mail: sales@purelinkav.com www.purelinkav.com For order support, please contact your local dealer. For technical support, please contact us at support@purelinkav.com...
-
Page 2: Table Of Contents
PureLink by Dtrovision Table of Contents 1-1 Package Contents 1-2 Description, General Specification 1-3 Environmental and Reliability Specifications 1-4 Supported I/O Resolutions 1-5 Panel Descriptions 1-6 Mechanical Specification 1-7 Technical Specification 1-8 Warranty Information p.10... -
Page 3: Package Contents
PureLink by Dtrovision 1-1 Package Contents Please make sure all of the following items are included in the package: 1) SC-SD2 Unit 2) DC 5V 3A Power supply adapter 3) User manual... -
Page 4: Description, General Specification
PureLink by Dtrovision 1-2 Description, General Specification Description Item Model SC-SD2 Input Signal HD-SDI Output Signal DVI/HDMI VIDEO YCbCr(422) Input format VIDEO Output format RGB(444), YCbCr(444), YCbCr(422) Input format I2S / 48Khz AUDIO DC Power Jack for +5V power in the rear panel... -
Page 5: Environmental And Reliability Specifications
PureLink by Dtrovision 1-3 Environmental and Reliability Specifications [Recommended Operating Conditions] Parameter Symbol Min. Typ. Max. Units Operating Temp. + 40 °C Storage Temp. + 60 °C Storage Humidity... -
Page 6: Supported I/O Resolutions
PureLink by Dtrovision 1-4 Supported I/O Resolutions VIDEO INPUT Output - Data SMPTE format YCbCr(4:2:2) Format Output - Connector SDI BNC SMPTE-424M 1080p (60/59.94) SMPTE-274M 1080i (60/59.94/50) Output Signal SMPTE-296M 1080p (25/24/23.976) Resolution SMPTE-260M 720p(60/59.94/50) SMPTE-259M 480i (59.94), 576i(50) VIDEO OUTPUT DVI/HDMI format Input –... -
Page 7: Panel Descriptions
PureLink by Dtrovision 1-5 Panel Descriptions < Front-Video Input > - Power switch - Power indicator light - Firmware update PS2 port (Programmer use only) - HD-SDI outputs < Rear-Video Output > - Status indicator LED 1) Video sync detection LED... -
Page 8: Mechanical Specification
PureLink by Dtrovision 1-6 Mechanical Specification [Dimensions] SC-SD2: 117 x 105 x 33 (mm) [Connector] - DVI Connector: DVI-I 29-pin female (Digital only) - HDMI Connector: HDMI female - HDSDI/SDI Connector: BNC female - Firmware Download Port: PS2 female [Power]. -
Page 9: Technical Specification
PureLink by Dtrovision 1-7 Technical Specification [Data rates and Maximum resolution] Data rates and Resolution Input Video Bandwidth 2.97Gbps Output Video Bandwidth 2.97Gbps Maximum Input Resolution 1920x1080p/60Hz Maximum Output Resolution 1920x1080p/60Hz ※ The HDMI input is prior to DVI input when HDMI and DVI port is concurrently connected to video... - Page 10 PureLink shall not be liable for any damages whatsoever caused by Product or the failure of Product to perform, including incidental or consequential damages. PureLink shall not be liable for any claim made by a third party or made by the purchaser for a third party.
