User Guide
System Telephone
System Telephone ST 31

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST 31 and is the answer not in the manual?

Questions and answers

Related Manuals for AGFEO ST 31

Summary of Contents for AGFEO ST 31

  • Page 1 User Guide System Telephone System Telephone ST 31...

  • Page 2: Safety Notice

    - AS 40 P (P400-1), AS 4000 (P400-1), AS 100 IT (P400 IT), AS 43, AS 45, AS 200 IT fromFirmware 7.6 - all other AGFEO Telephone Systems with a Firmware below 7.1 will emulate the ST 31 as an ST 30 System Phone.

  • Page 3: Table Of Contents

    Location ............................... 16 Cleaning ............................... 16 Insert Button Designation Strip ......................16 DHSG Headset (Cordless Headset) ...................... 17 Connection of Headset ........................17 DSHG Headset Operation ........................18 ST 31 Firmware Upgrade ........................18 Change of Opertion in Emulation Mode ....................18...

  • Page 4: View Of Base

    STE 40 Console Untangler Connection The ST 31 handset offers a compartment for the connection of a cord untangler. As the optional untangler is fitted inside the handset it will not interfere in normal use or when the receiver is put back on hook.

  • Page 5: Display Position

    Please follow the instruction in the display of the phone. It may be useful to allocate an extension number to the ST 31 before this is...

  • Page 6: Buttons

    System Telephone ST 31 Buttons 4-Line Display Speaker (below Hand- 10 Function But- set) tons with LED's Function Button Label Insert Microphone Numeric Keypad Message Waiting LED - Flashes on new entry in the call log or missed call. Permanent lit for * and # Buttons numbers already viewed.

  • Page 7: Status Display

    System Telephone ST 31 Status Display Status display of internal WK43 Fr 27.Oct.06 11:52 and external S0 Bus and Display of enabled analogue lines *${}%“S xiXIA- features. 13 15 17 18 23 24 30 32 Extension Numbers 41 52 will be displayed if they are off hook or ringing.

  • Page 8: Function Buttons - Freely Programmable Function Buttons (Overview)

    System Telephone ST 31 Function Buttons - Freely programmable Function Buttons (overview) TAM activation To switch answering machine on or off (optional module) To listen to recorded messages. TAM info To record memo on the TAM TAM Memo Reject an incoming call. Caller will hear busy tone.
  • Page 9 System Telephone ST 31 Function Buttons - Freely programmable Function Buttons (overview) Call Pick Up To Pick Up a call ringing on another extension. A Special Function Button may be assigned for this feature. To withhold own number being forwarded to the number called.

  • Page 10: Led - Display For Freely Programmable Function Buttons

    System Telephone ST 31 LED - Display for freely programmable function buttons LED on LED off LED flashes Answering Machine Stored messages No Messages New Messages Messages already listened enabled disabled Call Waiting activation Call Log entries No numbers in...
  • Page 11 System Telephone ST 31 LED - Display for freely programmable function buttons LED on LED off LED flashes LED flashes (slowly) (fast) TAM switched TAM Activation switched off Exclusiv Hold. Extension Button Extension The button is allocated to an Busy or off...

  • Page 12: Button Assignment

    System Telephone ST 31 Button Assignment Announce Call Waiting In default all System Phone Buttons are pre-programmed with the System Memory System Memory same functions. Tone Call Appointment System Memory System Memory Functions of each button can be changed to accommodate an...

  • Page 13: Call Waiting

    System Telephone ST 31 Call Waiting First Option: T Q P ª You are on a call and End Call Waiting Call will Lift Hand- Speak to Caller hear the call waiting ring tone. Second Option: Press the Button “Call Split or Brokers Call“ . The first call is put on hold and you are connected to the second caller.

  • Page 14: Display Call Log

    System Telephone ST 31 Display Call Log The handset is on hook. The Message Waiting LED is flashing. There will be at least one new entry in the Call Log. The Message Waiting LED will flash until the new entries have been displayed, after which the LED will remain lit until you return the call to the displayed number or delete the entry.

  • Page 15: Recent Numbers Redial

    System Telephone ST 31 Phonebook (Vanity retrieval) Select the next letter, ie M = 6. Pick up handset or press Press Enter the first letter, ie. A=2. The The first entry with “Am“ will “Speaker Phone Button“. The Phonebook first entry with this letter will be be displayed selected entry will be dialled.

  • Page 16: Location

    Insert Button Designation Strip Your ST 31 includes a printed designation strip which shows the button allocation in default. You may use the reverse to enter your own designations.

  • Page 17: Dhsg Headset (Cordless Headset)

    - insert the headset plug into the headset socket until you hear a positive click. - lay the cable in the cable duct underneath the ST 31 which is also used as a strain relief - to unplug the cable, release the latch on the plug (use a small screw driver if required) and at the same time pull the plug out of the socket.

  • Page 18: Dshg Headset Operation

    - If so required you may disable the ringer of the ST 31 but still will hear a call ringing directly in the earpiece of your headset. This will be ideal for call centres or open plan offices.
  • Page 19 System Telephone ST 31...
  • Page 20 Ident no. 1101627 Subject to change without notice. No liability AGFEO GmbH & Co. KG can be accepted for errors contained in this Gaswerkstr. 8 document.
