Analog Devices MICROCONVERTER ADUC812 Reference Manual page 2

Evaluation Board Reference Guide:
1) Evaluation Board Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2) Evaluation Board Features . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3) Link options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4) External Junctions (Connectors) . . . . . . . . . . . . . . . . . . . . . . . 9
5) LDR Demonstration Circuit . . . . . . . . . . . . . . .
6) Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
(1) E
The ADuC816 Evaluation board has the following features :
• 2 Layer PCB (4" X 5" Form Factor)
• 9V power supply/battery regulated to 5V on board (see section 2)
• 4 Pin Header Interface to RS232 dongle cable
• Access to all ADC inputs from external header. DAC output channel buffered to external header.
(see section 2 and section 4)
• All device Ports and Strobes are brought out to external header pins (see section 4)
• General Purpose Prototype Area (see section 2)
• 32KBytes External memory (SRAM) (configurable as data or volatile program memory) (see
section 2 and section 3)
• External Program Memory Socket for NV program memory (see section 2)
• 11.0592MHz Crystal (see section 2)
• Reset/External Interrupt 0 Push Buttons (see section 2)
ADuC812 Evaluation Board Reference Guide
C
ONTENTS
B
VALUATION
:
O
OARD VERVIEW
Evaluation Board Overview
11
