MVC-Data GC630 User Manual page 41

AccessZone® - PcManagement™ User Manual
"Gate" specifies how the door/barrier/gate is activated:
It supports 3 different door/gate output types to support different door/gate mechanisms.
All types can be combined with a warning buzzer period before gate activation (warning
buzzer can also be switched off)
"Pulse"
A 1 second pulse is used to activate the gate and another 1 second pulse is used to close
the gate again after the timeout of the "Remain gate open time" period.
Door/Gate Output
"Level"
A pulse is used to activate the gate. The length of the pulse depends on the "Remain gate
open time" period or if "Keep Open" feature is enabled and active.
Door/Gate Output
"Latched" (toggle)
The output is kept active (ON) from one valid access to the next where it changes back
(toggle).
Door/Gate Output
Select the type suitable for your door, barrier or gate. Please refer to the door/barrier/gate
manual for how to control it.
TIP!
A barrier and a gate is usually a "Pulse" type. However, some barriers and gates have a
built-in close timer. Use the "Level" type with a 1 s "Gate remain open time" to get a
single open pulse.
A normal entry door with a door strike is usually a "Level" type.
Latch (toggle) can be used with both doors/barriers/gates. It is recommended to use a
user access PIN code with this type of signal. Specail care must be taken when using the
latched mode with the alarm arming procedure. Refer to 8.1.2 Alarm Arming and
Disarming
The open signal can be inverted by changing the I/O settings. Refer to Input/Output
Settings - Menu "IO Setup"
All information is subject to change without notice. All other products and brand names are registered trademarks of their respective companies
Copyright © 2005-2014 All rights reserved MVC-Data ApS Skalhuse 5 9240 Nibe Denmark Web www.mvc-data.com E-mail info@mvc-data.com Phone +45 25 12 84 02
Remain open time
_____| |______________________|
Warning open time with buzzer
Remain open time
_____|
Warning open time with buzzer
_____|
.....................
Warning open time with buzzer
|___
Warning close time with buzzer
|___
Warning close time with buzzer
|___
Warning close time with buzzer
