The following components are located on the top of the instrument:
1: connectors compartment with voltage and current measurement connectors;
2: printer.
The following figure shows the layout of these components.
2.5
HANDLING THE INSTRUMENT
Adjustable Handle: the handle can be adjusted as required to support the instrument at the angle for display
readability.
Shoulder Strap Hooks: The shoulder strap provided with the kit can be used for carrying the instrument. The handle
has special holes into which the shoulder strap hooks can be inserted.
Printer Access: to open the printer compartment, simply press lightly on the ribbed section of the printer cover as
shown.
Fig. 2.3
Printer compartment
closed
4
1
2
Shoulder strap
anchorage points
Printer compartment
open
