MICROVIP3 PLUS
Rear panel selector in
"1- Φ Φ Φ Φ " (single-phase) position.
t
ype Automatic Printout type
0 = V
kVA
+ kWh
- kWh
Peak kVAr
(Typical printing time = 1 minute)
1 = V, I waveforms
(Typical printing time = 3 minutes )
2 = 1-24th Harmonics and DC component
of Voltage and Current expressed as absolute
value and in percentage referred to the
fundamental;
Total Harmonic Distortion Factors of Voltage
and Current;
Displacement Factor (Cosø of the fundamental);
Harmonics Voltage and Current bar-graph
diagram ;
(Typical printing time = 5 minutes)
Note: printing time depends on battery charge
.
A P.F. kW
kVAr Hz
+ kvarh
- kvarh
Peak kVA Peak kW
Rear panel selector in
"3- Φ Φ Φ Φ " (three-phase) position.
t
ype
0 =
Peak kVAr
1 = V1, V2, V3 waveforms
(Typical printing time = 3 minutes )
3 = I 1, I2, I3 waveforms
(Typical printing time = 3 minutes )
2 = 1-24 th Harmonics and DC component of
L1, L2, L3 Voltages and Currents expressed as
absolute value and in percentage referred to the
fundamental;
Total Harmonics Distortion Factors of L1, L2,
L3 Voltages and Currents ;
L1, L2, L3 Displacement Factors (Cosø of the
fundamental) ;
L1, L2, L3 Harmonic Voltages bar-graph
diagrams ;
(Typical printing time = 5 minutes)
4 = 1-24 th Harmonics and DC component of
L1, L2, L3 Voltages and Currents expressed as
absolute value and in percentage referred to the
fundamental;
Total Harmonic Distortion Factors of L1, L2,
L3 Voltages and Currents;
L1, L2, L3 Displacement Factors (Cosø of the
fundamental);
L1, L2, L3 Harmonic Currents bar-graph
diagrams ;
(Typical printing time = 5 minutes)
32
TIMED PRINTOUT FORMAT
Automatic Printout type
V A P.F.
kVA kVAr
+ kWh + kvarh
- kWh - kvarh
Peak kVA
VL1 VL2 VL3
AL1 AL2 AL3
kW1 kW2 kW3
P.F.1 P.F.2 P.F.3
(Typical printing time = 1 minute)
kW
Hz
Peak kW
