Elcontrol Microvip 3 plus User Manual

Portable energy and harmonics analyzer for unbalanced 1 - and 3 - phase systems
Hide thumbs
Table of Contents

Advertisement

Quick Links

MICROVIP3 Plus
PORTABLE ENERGY AND HARMONICS ANALYZER FOR
UNBALANCED 1 - AND 3 - PHASE SYSTEMS
USER MANUAL
ELCONTROL ENERGY NET SPA Via Vizzano 44 40044 Pontecchio Marconi (Bologna) - Italy -
Tel. 0039 051 6782006 Fax 0039 051 845544

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Microvip 3 plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Elcontrol Microvip 3 plus

Summary of Contents for Elcontrol Microvip 3 plus

  • Page 1 MICROVIP3 Plus PORTABLE ENERGY AND HARMONICS ANALYZER FOR UNBALANCED 1 - AND 3 - PHASE SYSTEMS USER MANUAL ELCONTROL ENERGY NET SPA Via Vizzano 44 40044 Pontecchio Marconi (Bologna) - Italy - Tel. 0039 051 6782006 Fax 0039 051 845544...
  • Page 2 MICROVIP3 PLUS MENU SHORT FORM PUSHBUTTONS FUNCTION TO BE USED PAGE MOVING ON THE SAME MENU LEVEL PAGE (3 sec.) PASSAGE TO A LOWER MENU LEVEL SEL + SET = SEL = select digit SET = change digit EDITING = change value PAGE/ENTER ESCAPE TO (for 3 sec.)
  • Page 3 MICROVIP3 PLUS SET UP PAGES SHORT FORM SEt-UP MEAS 12 pages of three-phase measurements 7 pages of single-phase measurements Use SEL and SET to select baud rate (1200 2400,4800,9600 19200,38400 * Note 1: these 3 pages are present only when LOG off. data bits (7/8), stop bits (1/2), parity (no/e/o).
  • Page 4 INDEX USER SAFETY............................1 INTRODUCTION............................. 1 SAFETY PRECAUTIONS ........................1 SYMBOLS ..............................1 PRECAUTIONS IN CASE OF MALFUNCTIONING ................1 INTRODUCTION TO THE MICROVIP3 PLUS ................... 2 MAIN FEATURES ..........................2 GREAT VERSATILITY.......................... 2 PURPOSE AND USE ..........................2 DESCRIPTION OF THE INSTRUMENT ....................3 HANDLING THE INSTRUMENT ......................
  • Page 5 PRIMARY MEASUREMENTS ........................ 37 8.4.1 PRIMARY MEASUREMENTS ACCURACY ..................37 8.4.2 SECONDARY MEASUREMENTS ACCURACY ................... 38 DISPLAYED (AND PRINTED) VALUES ....................38 8.5.1 ADDITIONAL MEASUREMENTS OF THE PRINTER ................. 39 FORMULAE .............................. 39 8.6.1 SINGLE-PHASE FORMULAE ......................... 39 8.6.2 THREE-PHASE FORMULAE ........................40 8.6.3 HARMONIC FORMULAE ........................

  • Page 6: User Safety

    USER SAFETY − This instrument has been manufactured and tested to the standards laid down in IEC 1010-1 600V with regard to category III installation and level of protection 2 under IEC 664-664A. − It has left our factory in perfect working order. −...

  • Page 7: Introduction To The Microvip3 Plus

    The MICROVIP3 PLUS is a low cost, class 1 (IEC1036) high technology portable analyzer for both single phase and three phase systems, manufactured by ELCONTROL ENERGY and supplied complete with three 1000A clip-on CTs, voltage leads and all accessories in strong carry case.

  • Page 8: Description Of The Instrument

    3-PHASE ENERGY & HARMONIC ANALYZER PRINT PAGE PRG SELC SETC PAPER ELCONTROL energy Fig. 2.1 The following components are located on the rear panel: 1: mains power socket (for use with cable provided); 2: removable fuse-holder for safety fuse; 3: ON (I)/STANDBY (O) switch for activation of instrument;...

  • Page 9: Handling The Instrument

    The following components are located on the top of the instrument: 1: connectors compartment with voltage and current measurement connectors; 2: printer. The following figure shows the layout of these components. Fig. 2.3 HANDLING THE INSTRUMENT Adjustable Handle: the handle can be adjusted as required to support the instrument at the angle for display readability.
  • Page 10 Replacing the printer cartridge: open the printer compartment and press down on the area marked PUSH to remove the old cartridge. Fit the new cartridge and push gently down into position. PUSH Replacing the printer roll: open the printer compartment and press down gently on the area marked PUSH to remove the printer cartridge.

  • Page 11: Installation

    PRELIMINARY INSPECTION When you receive your MICROVIP3 PLUS, check that the kit is complete and that the instrument has not been damaged in transit. Refer to ELCONTROL ENERGY service network for any repair or replacement. 3.1.1 KIT CONTENTS The instrument comes in a practical impact resistant case and with a number of accessories. The complete kit should...

  • Page 12: Instrument Power

    INSTRUMENT POWER 3.3.1 MAINS POWER The kit includes a power cable for connection to the mains supply. Make sure that mains power is 230VAC ± 10% 50/60 Hz (or 110VAC ± 10% 50/60 Hz if your version is designed for this rating).

  • Page 13: Measuring Connections

    MEASURING CONNECTIONS The connectors for use in voltmeter and ammeter connections are located in the top of the instrument. INPUT CURRENT INPUT VOLTAGE Connectors for Connectors for current measurements voltage measurements Follow these instructions carefully to avoid measurement errors. 3.4.1 VOLTMETER CONNECTIONS Use the cables supplied for the purpose in the kit.

  • Page 14: Operation

    OPERATION 4.1.1 MEASURING THREE PHASE POWER (STAR SYSTEM) Set the connection type selector on the rear panel to 3 ø (THREE-PHASE) (see Fig. 4.1). 230V ± 10% 3 ø DISPLAY 50/60 Hz 4VA RS232C LIGHT FUSE 80mA T 250V- 1 ø Fig.

  • Page 15: Measuring Three Phase Power (Delta System)

    4.1.2 MEASURING THREE-PHASE POWER (DELTA SYSTEM) (R) L1 (S) L2 (T) L3 Fig. 4.3.2 Connect L1, L2, L3; then connect the neutral voltage input to L3. Note: Select Delta in Set-up Pages Menu 4.1.3 MEASURING TWO PHASE POWER Fig. 4.3.3 Connect L1 and L2;...

  • Page 16: Measuring Single Phase Power (Phase-Neutral)

    (e.g. inverters, U.P.S., rectifiers), use the Hall effect clamp meters designed for these applications which are available from the ELCONTROL ENERGY accessories catalogue. Use the ADAPTA-1V/1V adapter (code 4AACQ) for connections to the MICROVIP3 PLUS as shown in fig. 4.5 for the phase L1 inputs and in figs. 4.6 and 4.7 for three phase systems (taking care to ensure that voltage and current inputs correspond).

  • Page 17: Special Connections

    When using current transformers or current measuring clamp meters other than those supplied, use adapter interfaces INTA/1 (code 4AABB) and INTA/5 (code 4AABD), as listed in the ELCONTROL catalogue. 1) Connect the CT secondary to the INTA/1 or INTA/5 interface.

  • Page 18: The Inta/1 And Inta/5 Interfaces

    In these cases, use an insulating transformer (fig. 4.10), or three SEPA 5X1 interfaces (code 4AAER) available in the ELCONTROL ENERGY accessories catalogue. Fig. 4.9 (R) L1...
  • Page 19 4.4.3 (R) L1 (S) L2 (T) L3 Connection to 2 voltage transformers with one phase of the secondary grounded DELTA Connection to 3 star voltage transformers with one phase of the secondary grounded DELTA (R) L1 (S) L2 T) L3 Connection to 3 star voltage transformer (PTs) STAR...

  • Page 20: Microvip3 Plus Operating Modes

    3-PHASE ENERGY & HARMONIC ANALYZER PAGE PRINT CosΦ SELC SETC PAPER P.F. ELCONTROL energy Press page key to display next pages Second page (single-phase) kVAr: Reactive power. kVA: Apparent power. Hertz: voltage Frequency, range 20 to 600 Hz (AC) and 00 Hz (DC).
  • Page 21 SELC SETC PAPER ELCONTROL energy Fifth page (single-phase) kVAr : Average Reactive power peak of the single phase system kVA : Average Apparent power peak of the single phase system kW : Average Active power peak of the single phase system (Maximum demand) Peak values are memorized and displayed only after an integration period of 1, 2, 5, 10, 15, 20, 30 or 60 minutes from the time the instrument is first switched on.

  • Page 22: Energy Consumption And Maximum Demand Reset

    SELC SETC PAPER ELCONTROL energy If you press the SET button while the fifth page is displayed, the active and reactive power peak values are reset to zero. The buffer used to calculate average power is also cleared, and this measurement therefore remains invalid until the programmed integration time has elapsed again.

  • Page 23: Three Phase Mode

    SELC SETC P.F. PAPER 3 ø ELCONTROL energy Second page ( three-phase) Volt L1: Rms voltage between phase L1 and neutral (STAR) Rms voltage between L1 and L3 (DELTA) Volt L2: Rms voltage between phase L2 and neutral (STAR) Rms voltage between L2 and L3 (DELTA)
  • Page 24 PAGE PRINT SELC SETC PAPER ELCONTROL energy Fifth page (three-phase) P.F. Cosø L1 : Phase L1 power factor P.F. Cosø L2 : Phase L2 power factor P.F. Cosø L3 : Phase L3 power factor (only in three-phase, STAR; missing in DELTA) MICROVIP3 Plus 3-PHASE ENERGY &...
  • Page 25 SELC SETC PAPER 3 ø ELCONTROL energy Ninth page (three-phase) kVAr : Average reactive power peak of the three phase system kVA : Average apparent power peak of the three phase system : Average active power peak of the three phase system...

  • Page 26: Energy Consumption And Maximum Demand Reset

    PRINT SELC SETC PAPER ELCONTROL energy 5.2.2 ENERGY CONSUMPTION AND MAXIMUM DEMAND RESET The SET button resets to zero the electrical energy consumption counts (KVArh, KVArh and kWh) and the average three phase active, reactive and apparent power peak values.
  • Page 27 5.2.3 SETUP PAGES MENU To access this menu, press the SEL key. To exit from this menu, SEt - UP press the PAGE key for 3 seconds. To change the page, press the PAGE key. First page Use SEL and SET to select PT primary (from 1 to 999999V) and 0 0 0 1 0 0 PT secondary ( 57.7, 63.5, 100, 110, 115, 120, 173, 190, 220V).
  • Page 28 Sixth page Use the SET key to select a 50 Hz or a 60 Hz fundamental frequency OFF = no harmonic measurements and printouts 50 Hz Fnd = thd referred to the fundamental instead of rms value Factory default : OFF 60 Hz Fnd 50 Hz Fnd 60 Hz...

  • Page 29: Print Functions

    LCD (see the following table). MICROVIP3 Plus 3-PHASE ENERGY & HARMONIC ANALYZER PAGE PRINT PRG SELC SETC PAPER ELCONTROL Energy Press PRINT key to print out all measurements taken by instrument...
  • Page 30 MICROVIP3 PLUS MANUAL PRINTOUT FORMAT Pressing "Print" button with rear Pressing "Print" button with rear panel selector in "1-Φ Φ Φ Φ " (single-phase) panel selector in "3-Φ Φ Φ Φ " (three-phase) position: position: Measurement page Printout format Measurement page Printout format In Pg.1,2,3,4,5,7 →...

  • Page 31: Timed Printing

    5.3.2 TIMED PRINTING This function enables you to specify a time interval at which the instrument automatically prints out up-to-date measurements and graphs. The timed printout interval and the Automatic Printout type are programmed using the calendar-clock (see 5.4 ). Timed printouts formats are the same than in manual printing but without the indication "...
  • Page 32 MICROVIP3 PLUS MANUAL PRINTOUTS: SINGLE-PHASE TYPE 2 (1-ø ) corrsponding to : see Manual Printout Format pg. 25 TYPE 0 (1-ø ) corresponding to : see Manual Printout Format pg. 25 TYPE 1 (1-ø ) corresponding to : see Manual Printout Format pg. 25...
  • Page 33 MICROVIP3 PLUS MANUAL PRINTOUTS: THREE-PHASE TYPE 1 (3-ø) corresponding to : TYPE 3 (3-ø) corresponding to : see Manual Printout Format pg. 25 see Manual Printout Format pg. 25 TYPE 0 (3-ø) corresponding to : see Manual Printout Format pg. 25...
  • Page 34 MICROVIP3 PLUS MANUAL PRINTOUTS: THREE-PHASE TYPE 2 (3-ø) corresponding to : see Manual Printout Format pg. 25...
  • Page 35 MICROVIP3 PLUS MANUAL PRINTOUTS: THREE-PHASE TYPE 4 (3-ø) corresponding to : see Manual Printout Format pg. 25...

  • Page 36: The Calendar Clock

    THE CALENDAR CLOCK The instrument's calendar clock displays TIME, DAY, MONTH, and YEAR on an LCD on the front panel. The clock also allows to program the type and the intervals for timed (automatic) printouts. You can use the PRG, SELC and SETC buttons underneath the clock display to control clock funtions.
  • Page 37 MICROVIP3 PLUS TIMED PRINTOUT FORMAT Rear panel selector in Rear panel selector in "3- Φ Φ Φ Φ " (three-phase) position. "1- Φ Φ Φ Φ " (single-phase) position. Automatic Printout type Automatic Printout type P.F. P.F. kVAr kVAr + kWh + kvarh + kWh + kvarh...
  • Page 38 Press the PRG button to enter Printing Interval selection page. A "P" and two zeros are displayed initially. These represent the tens and units of the printing interval. Simply set the number of minutes you require for the interval between one printout and the next. SELC SETC Press the SELC button to switch between the tens and the units.

  • Page 39: Pc Software

    MICROVIP3 PLUS to a RS485 monitoring network: its address is fixed to 1. PC SOFTWARE ELCONTROL ENERGY PC softwares for data acquisition are : - VIPVIEW (code 4AAGW) - Win95/98 general purpose software for supervision, control and energy data acquisition...

  • Page 40: The On Board Memory

    One 3,5V 280mAh lithium battery as memory buffer (guaranteeing memory backup for approximately 7 years). IMPORTANT: when the lithium back-up battery is changed, date and time are lost. Battery replacement must be carried out by qualified, authorized staff at ELCONTROL ENERGY service centres. • Measurement display: Backlight LCD with temperature range of -30°C to +80°C.

  • Page 41: Operating Conditions And Testing

    OPERATING CONDITIONS AND TESTING • Environmental operating conditions: Environmental temperature range: from -10°C to +50°C. Relative humidity (R.H.): from 20% to 80%. • Storage temperature: from -20°C to +60°C. • Condensation: non-condensing environment. • Insulation resistance: ≥ 500 MΩ between voltmeter input connectors short-circuited between each other and instrument frame, between power socket and instrument frame.

  • Page 42: Primary Measurements

    8.4.1 PRIMARY MEASUREMENT ACCURACY • Measurement error in environment of 18° ° ° ° C to 25° ° ° ° C (after 10’ warming up): expressed as ± % Rdg. (reading) + % F.S. (Full Scale) – see tables. • Additional measurement error outside this temperature range: ±...

  • Page 43: Displayed (And Printed) Values

    DISPLAYED AND PRINTED VALUES 3ø 8.5.1 ADDITIONAL MEASUREMENTS OF THE PRINTER...

  • Page 44: Formulae

    8. 6 FORMULAE 8.6.1 SINGLE PHASE FORMULAE )² ∑ True rms voltage ) . (a ∑ Active power P. F. = W / VA Power factor ∑ )² True rms current Apparent power . ( ) VAr = Reactive power ∑...

  • Page 45: Harmonic Formulae

    Three phase apparent power ∑ ∑ ∑ CosΦ / VA Equivalent three phase ∑ ∑ ∑ power factor 8.6.3 HARMONIC FORMULAE ∑ ∑ THDF V = Total Harmonic Distortion Factor of Voltage THDF A = Total Harmonic Distortion ∑ ∑ Factor of Current = V, I where...

  • Page 46: On Board Memory Specifications

    • Construction standards: (LVD) IEC 1010-1, IEC 1010-2-032 600V CAT III, pollution degree 2 (EMC) EN50081-1 class B EN50082-2 • Overload protection: Max. 1200 A for 40' • Output impedance: 1Ω. ON BOARD MEMORY SPECIFICATIONS • Size: 1 Megabyte (7840 records in Standard LOG, 677 records in Sample LOG) •...
  • Page 47 ANNEX A Characteristics of the MICROVIP3 PLUS Rs232 serial communication software protocol The software communication protocol complies with the ASCII (7 bits) MODBUS protocol. - Selected transmission mode: ASCII - Coding system: HEX (uses printable ASCII characters: 0-9, A-F). - Error detection mode: LRC - Serial protocol characteristics: - Baud rate: 1200, 2400, 4800, 9600, 19200, 38400...
  • Page 48 WRITING OF 1 BIT P.C. MICROVIP3 PLUS :,AA,05H,NNNN,bbbb,LRC,CR,LF - - - - - - -> <- - - - - - -:,AA,05H,NNNN,bbbb,LRC,CR,LF where: - AA = 01 = address of the MICROVIP3 PLUS (2 bytes ASCII) - 05H = Code of the command for writing of 1 bit (2 bytes ascii) - NNNN = Number of the bit to be written (4 bytes ascii): 0000H <= Number of the bit <= 0003H or number of the bit = FFFEH...
  • Page 49 :01 06 00 40 FD 00 Check CR LF - CT primary = 1000 exp 0 = 1000 A - CT secondary = 1000 exp –3 = 1.000 V - CT K = 1000 / 1 = 1000 A. / 1 V - Writing in eeprom of the PT coefficient K (2 consecutive writing commands) -1) SSSS = 0030H:...
  • Page 50 NOTE: Only bit 7 of datum D1 is written at the address indicated; D2 is processed as a template of the bit to be written but is not written. NOTE: If for any reason only one of the two writing commands is written (because of a break in the line, etc.) the malfunction must be recorded (on P.C.) since after each command the selection bit is immediately updated.
  • Page 51 Reading string : : 01 03 003A 0004 BE CR LF Response from MICROVIP3 PLUS : : 01 03 08 E8030000E8 03 FD 00 21 CR LF - Reading in eeprom of the PT coefficient K P.C. MICROVIP3 PLUS :,AA,03H,002E,0004, LRC, CR,LF ------>...
  • Page 52 = 01= address of the MICROVIP3 PLUS selected (2 bytes ascii) -03H = Code of the command for reading of N words (2 bytes ascii) -0000 = address from which the reading starts (4 bytes ascii) -0001 = Number of words to be read (2 bytes ascii) -LRC = Longitudinal Redundancy Check (2 bytes ascii) = 0DH (1 byte ascii)
  • Page 53 - Reading in eeprom of the flag for selection of Standard /Cogeneration 4 P.C. MICROVIP3 PLUS :,AA,03H,0000,0001, LRC, CR,LF ------> <------ :,AA,03H,02,D1,D2,LRC,CR,LF where: = 01 = address of the MICROVIP3 PLUS selected(2 bytes ascii) -03H = Code of the command for reading of N words(2 bytes ascii) -0000 = address from which the reading starts (4 bytes ascii) -0001...
  • Page 54 LIST OF THE ERROR STRINGS IMPLEMENTED AND THEIR MEANING ILLEGAL FUNCTION. Error generated by reception of an unknown function code. P.C. MICROVIP3 PLUS <- - - - - - - :,AA,FF,01H,LRC,CR,LF where: - AA = 01 = address of the MICROVIP3 PLUS (2 bytes ASCII) - FF = Code of the command received with bit 7 forced to 1 (2 bytes ascii);...
  • Page 55 - Initial character error (":") - Address selected not valid - LRC error - CR error - LF error - Any type of error detected on a "radio broadcasting" command (address = 00H). HOW THE LRC IS CALCULATED The LRC is calculated as follows. - all the bytes to be transmitted before the LCR are added together, except for the string start character (:).
  • Page 56 Description of the operational reading functions implemented READING OF ALL MEASUREMENTS This is carried out by reading 65 words starting from the address 0810H or 0FE00H. The meaning of the 130 bytes received is as follows: - Type of instrument (TIPVIP = 0DH = 13 (Vip Energy)) - Instrument options (OPTION) (1st byte): bit 7 = 0 (not used) ==>...
  • Page 57 - Phase L3 active power (W) - Phase L1 cosø - Phase L2 cosø - Phase L3 cosø - Phase L1 reactive power (VAr) - Phase L2 reactive power (VAr) - Phase L3 reactive power (VAr) - Phase L1 apparent power (VA) - Phase L2 apparent power (VA) - Phase L3 apparent power (VA) - 6 ASCII characters = 30 Hex...

  • Page 58: A.2 Q-Basic Example For Microvip3 Plus Reading

    A.2 Q-Basic example for MICROVIP3 PLUS reading EXAMPLE OF MICROVIP3 PLUS READING INSTRUMENT TYPE : MICROVIP3 PLUS PHISICAL ADDRESS : 01 TRANSMISSION PARAMETERS : 9600 baud, NO par, 1 Stop BIT DECLARE SUB Pause (n!) DECLARE SUB SetArrayMeasures () DECLARE FUNCTION CheckLrc! (EnergyReply$) DECLARE SUB ShowData (EnergyReply$) DECLARE FUNCTION AsciiToFloat! (Data$) DECLARE FUNCTION AsciiHexToDec! (A$)
  • Page 59 Num$ = "" FOR k = 1 TO LEN(Data$) - 3 STEP 2 'Rewrites the whole number from the most significant couple of digits ' to the last significant Num$ = MID$(Data$, k, 2) + Num$ NEXT k IF LEFT$(Num$, 1) = "8" THEN 'Negative number Num$ = "-"...
  • Page 60 EXAMPLE OF MODBUS PROTOCOL REQUEST to the instrument with address 01: ":010308100041A3"+CR+LF oppure ":0103FE0041BD"+CR+LF Start Transmission Instrument Address Command memory Address #words to read 0810 oppure FE00 0041 A3 oppure BD End Transmission 0D0A RESPONSE from instrum. 01 to all measurements request ":0103820D310040001204004301FE0101019980FE3802003802003802004301FE4301FE4301FE3703003703003703009980FE9980F 9980FE8084FF2484FF4784FF4103004003004003000000000000000000000201013581000005FF41010000FE61020000FE510200570 2002504FF10030154010100000000000000000000000000000000BF"+CR+LF...

  • Page 61: A.3 Reading Of Voltage And Current Waveform Samples

    A.3 Reading of Voltage and Current waveforms samples The PC Requests for 200 samples of V and I waveforms are: Phase 1: Phase 2: Phase 3: 0103040000202 Check CR LF :010305000202 Check CR LF :010306000202 Check CR LF Microvip3 Plus Response: :01 03 D1 D2 D3 D4 D5 D6 D7 D8 D9 V1..V200 D10 D11D12 D13D14 D15 D16 D17 I1..I200 CS CRLF Where: : = start of Modbus string...
  • Page 62 CWP0,CWP1,CWP2,CWP3,CWP4 = three-phase positive kWh (BCD) where CWP4 is the exponent (hexadecimal) CVARP0,CVARP1,CVARP2,CVARP3,CVARP4 = three-phase positive kvarh (BCD) where CVARP4 is the exponent (hexadecimal) CWN0,CWN1,CWN2,CWN3,CWN4 = three-phase negative kWh (BCD) where CWN4 is the exponent (hexadecimal) CVARN0,CVARN1,CVARN2,CVARN3,CVARN4 = three-phase negative kvarh (BCD) where CVARN4 is the exponent (hexadecimal) Example: :01 03 D1 D2 D3 D4 D5 D6 D7 D8 D9 V1..V200 D10 D11 D12 D13 D14 D15 D16 D17 I1..I200...

  • Page 63: A.4 On Board Memory Downloading

    On-board Memory downloading via serial line Use the following command sequence: 8 bit UART Setting In order to have a correct download of data stored, UART has to be set to 8 bits. N.B. This setup is necessary because the data stored inside the internal memory are in decimal format. PC Request: Microvip3Plus Response: :01 05 0006 0000 LRC crlf...
  • Page 64 D29 D30 D31 D32 D33 D34 21 03 45 67 89 56 ( positive Wh equal to 210345.678956 MWh ) where byte 21 = 2 Wh * 10 exp 11 + 1 Wh * 10 exp 10 byte 03 = 0 Wh * 10 exp 9 + 3 Wh * 10 exp 8 byte 45 = 4 Wh * 10 exp 7 + 5 Wh * 10 exp 6 byte...
  • Page 65 Example 2: PC Request: :010380000004 77 CR LF (request for 4 records of 113 bytes each, starting from the first address 8000h) Microvip3 Plus Response (hexadecimal value) in case of a campaign of samples in Three-phase, Standard 1 mode (i.e. kWh e kvarh energy meters ), Star insertion.
