Battery installation

Open the battery cover on the back side of the transmitter and put 4 alkaline
batteries (AA, not included) into the cavity in accordance with the electrode instructions
as shown in pictures 1 and 2
Picture 1
1. Make sure the electrodes are correct.
2. Do not mix new with old batteries.
Notice:
3. Do not mix different kinds of batteries.
4. Do not charge the non-rechargeable battery.
Phone Installation Instruction:
1. Pull up the phone holder( Picture 3), open the lower clamp, then pull the
upper holder until the phone can be held firmly in place(Picture 4).
2. Put the phone into the holder, then release the clamp where the phone
be held tightly( Picture 5/6).
Picture 3
4*1.5V
Alkaline Batteries
Battery Cover
Picture 4
9
Picture 2
Picture 5 Picture 6
